NetXtreme User Guide

Using WMI

No special configuration is required to use WMI on the Windows client. Perform the steps in the following
sections to configure WMI on the Windows server.

Step 1: Set up Namespace Security Using WMI Control

The WMI Control provides one way to manage namespace security. You can start the WMI Control from the
command prompt using this command:
wmimgmt
On Windows 9x or Windows NT4 computers that have WMI installed, use this command instead:
wbemcntl.exe
Alternatively, you can access the WMI Control and the Security tab as follows:
1. Right-click on My Computer and click Manage.
2. Double-click Services and Applications and then double-click WMI Control.
3. Right-click WMI Control and then click Properties.
4. In WMI Control Properties, click the Security tab.
5. A folder named Root with a plus sign (+) next to it should now be visible. Expand this tree as necessary to
locate the namespace for which you want to set permissions.
6. Click Security.
A list of users and their permissions appears. If the user is on the list, modify the permissions as appropriate.
If the user is not on the list, click Add and add the user from the location (local machine, domain, etc.) where
the account resides.
Note: You can add these exports at the end of the .bash_profile. This file is located in the /root
directory.
• In order to view and set namespace security, the user must have Read Security and Edit Security
permissions. Administrators have these permissions by default, and can assign the permissions
to other user accounts as required.
• If this user needs to access the namespace remotely, you must select the Remote Enable
permission.
• By default, user permissions set on a namespace apply only to that namespace. If you want the
user to have access to a namespace and all subnamespaces in the tree below it, or in
subnamespaces only, click Advanced. Click Edit and specify the scope of access in the dialog
box that displays.

Step 2: Grant DCOM Remote Launch and Activate Permission

In the Windows domain environment, the Domain Administrator account has the necessary privilege level to
access the WMI component for BACS management and, therefore, no special configuration is needed. In a
large enterprise, however, a user who is accessing the local or remote host using the BACS4 client GUI may
not always have the domain administrator account privilege. It is necessary to configure WMI security access
on the remote host to allow the user to connect to it using the BACS4 client GUI.
