NetXtreme User Guide
Notes:
• If the certificate was generated using the host name, enter the host name. If it was generated using
the IP address, enter the IP address. For an IPv6 address, use brackets [ ] around the address.
• If HTTPS is configured in your system, the listener must be deleted before creating a new HTTPS
listener. Use the following command:
winrm delete winrm/config/Listener?Address=*+Transport=HTTPS
a. The above command creates a listener on the HTTPS port (5986) using any/all network address of the
server, and my SelfSSL generated certificate.
b. You can use the
configured on any user defined port.
c. From command prompt, run the following command to verify that the listener(s) that have been
configured:
winrm e winrm/config/listener
1. Test HTTPS/SSL connection on the server.
a. At the command prompt on the server, enter the following command:
winrs -r:https://yourserver:5986 -u:username -p:password hostname
b. If set up correctly, the output of the command shows the server host name.
c. To check WinRM Service Configuration, run the following command:
winrm get winrm/config/service
Step 7: Additional Server Configuration
If necessary, modify the firewall rules as follows:
Windows Server 2008 R2
1. From the Administrative Tools menu, open Windows Firewall with Advanced Security.
2. Right-click Inbound Rules and select New Rule.
The new rule wizard opens.
3. Select Port and click Next.
4. On the Protocol and Ports screen, select TCP and enter the specific port, for example, 5985 for HTTP or
5986 for HTTPS.
5. Click Next.
6. On the Action screen, select Allow the connection and click Next.
7. For Profile, you can select all three profiles if your server is in a workgroup.
8. Specify a name for the rule and click Finish.
9. Ensure that the new rule and is enabled (the green check box is selected).
Windows XP
1. Click Start > Control Panel, and then double-click Windows Firewall.
2. Click the Exceptions tab
Broadcom ®
April 2017 • 2CS57XX-CDUM514-R
command to modify or set the HTTPS listener, as WinRM listeners can be
winrm
Windows Driver and Management Application Installation
Page 28
