NetXtreme User Guide
Note that the NIC # above does not correspond to the vmnic<#>. The NIC number is the system vmnic probe
order number. Optimally, the number of NetQueues matches the number of CPUs on the machine.

Driver Parameters

Several optional parameters can be supplied as a command line argument to the vmkload_mod command.
These parameters can also be set via the esxcfg-module command. See the man page for more information.

Driver Defaults

Parameter
Speed
Flow Control
MTU
Rx Ring Size
Rx Jumbo Ring Size
Tx Ring Size
Coalesce RX Microseconds
Coalesce RX Microseconds
irq
Coalesce rx frames
Coalesce rx frames irq
Coalesce TX Microseconds
Coalesce tx usecs irq
Coalesce tx frames
Coalesce tx frames irq
Coalesce stats usecs
MSI
WoL

Driver Messages

The following are the most common sample messages that may be logged in the file /var/log/messages. Use
to control the level at which messages will appear on the console. Most systems are set to
dmesg -n <level>
level 6 by default. To see all messages, set the level higher.
Driver Sign On
tg3.c:v3.118g (Jan 4, 2012)
NIC Detected
Broadcom ®
April 2017 • 2CS57XX-CDUM514-R
Table 4: VMware Driver Defaults
Default Value
Autonegotiation with all speeds advertised
Autonegotiation with rx and tx advertised
1500 (range 46–9000)
200 (range 0–511). Some chips are fixed at 64.
100 (range 0–255). Not all chips support the jumbo ring and some chips that
support jumbo frames do not use the jumbo ring.
511 (range (MAX_SKB_FRAGS+1) – 511). MAX_SKB_FRAGS varies on
different kernels and different architectures. On a 2.6 kernel for x86,
MAX_SKB_FRAGS is 18.
20 (range 0–1023)
20 (range 0–255)
5 (range 0–1023)
5 (range 0–255)
72 (range 0–1023)
20 (range 0–255)
53 (range 0–1023)
5 (range 0–255)
1000000 (approx. 1 sec.). Some coalescing parameters are not used or have
different defaults on some chips.
Enabled (if supported by the chip and passed the interrupt test).
Disabled
VMware Driver Software
