NetXtreme User Guide
5. From the Available Adapters list, click the adapter you want to add to the team and then click Add. Remove
team members from the Team Members list by clicking the adapter and then clicking Remove. Click Next.
Note: There must be at least one Broadcom network adapter assigned to the team.
The Large Send Offload (LSO) and Checksum Offload (CO) columns indicate if the LSO, and/or the CO
properties are supported for the adapter. The LSO, and CO properties are enabled for a team only when all
of the members support and are configured for the feature. If this is the case, then the team offload
capabilities appear on the bottom of the screen.
Note: Adding a network adapter to a team where its driver is disabled may negatively affect the
offloading capabilities of the team. This may have an impact on the team's performance. Therefore, it
is recommended that only driver-enabled network adapters be added as members to a team.
Broadcom ®
April 2017 • 2CS57XX-CDUM514-R
Using Broadcom Advanced Control Suite 4
Page 73
