The Diagnostic Tests option on the Diagnostics tab lets you check the state of the physical components on a
Broadcom network adapter. You can trigger the tests manually, or choose to have BACS 3 continuously perform
them. If the test are performed continuously, then the number of passes and fails in the Result field for each test
increments every time the tests are performed. For example, if a test is performed four times and there are no
fails, the value in the Result field for that test is 4/0. However, if there were 3 passes and 1 fail, the value in the
Result field is 3/1.
Notes:
• You must have administrator privileges to run diagnostic tests.
• The network connection is temporarily lost while these tests are running.
• Not all Broadcom adapters support each test.
To run the diagnostic tests once
1. Click the name of the adapter to test in the Explorer View pane and select the Diagnostics tab.
2. From the Select a test to run list, select Diagnostic Tests.
3. Select the diagnostic tests you want to run. Click Select All to select all tests or Clear All to clear all test
selections.
4. Select the number of times to run the tests from Number of loops.
5. Click Run test(s).
6. In the error message window that warns of the network connection being temporarily interrupted, click Yes.
The results are displayed in the Result field for each test.
This test verifies the read and write capabilities of the network adapter registers by writing
Control Registers.
various values to the registers and verifying the results. The adapter driver uses these registers to perform
network functions such as sending and receiving information. A test failure indicates that the adapter may not
be working properly.
This test verifies the read and write capabilities of the registers of the physical layer (PHY). The
MII Registers.
physical layer is used to control the electrical signals on the wire and to configure network speeds such as 1000
Mbit/s.
This test verifies the content of the electrically erasable programmable read-only memory (EEPROM)
EEPROM.
by reading a portion of the EEPROM and computing the checksum. The test fails if the computed checksum is
different from the checksum stored in the EEPROM. An EEPROM image upgrade does not require a code
change for this test.
This test verifies that the internal memory of the adapter is functioning properly. The test writes
Internal Memory.
patterned values to the memory and reads back the results. The test fails if an erroneous value is read back.
The adapter cannot function if its internal memory is not functioning properly.
This test verifies the operation of the internal CPUs in the adapter.
On-Chip CPU.
