NetXtreme User Guide
Option
Link Up Delay Time
Use TCP Timestamp
Target as First HDD
LUN Busy Retry Count
IP Version

MBA Boot Protocol Configuration

To configure the boot protocol
1. Restart your system.
2. From the PXE banner, select CTRL+S. The MBA Configuration Menu appears (see
3. From the MBA Configuration Menu, use the UP ARROW or DOWN ARROW to move to the Boot Protocol
option. Use the LEFT ARROW or RIGHT ARROW to change the Boot Protocol option to iSCSI.
Note: For platforms on which the boot protocol is set via the BIOS, see your system documentation
for more information.
4. Select iSCSI Boot Configuration from Main Menu.
Note: If iSCSI boot firmware is not programmed in the NetXtreme network adapter, selecting iSCSI
Boot Configuration will not have any effect.

iSCSI Boot Configuration

• Static iSCSI Boot Configuration
• Dynamic iSCSI Boot Configuration
Static iSCSI Boot Configuration
In a static configuration, you must enter data for the system's IP address, the system's initiator IQN, and the
target parameters obtained in
Table 17.
To configure the iSCSI boot parameters using static configuration
1. From the General Parameters Menu screen, set the following:
• TCP/IP parameters via DHCP: Disabled. (For IPv4.)
• IP Autoconfiguration: Disabled. (For IPv6)
Broadcom ®
April 2017 • 2CS57XX-CDUM514-R
Table 17: Configuration Options (Cont.)
Description
Controls how long the iSCSI boot host software waits, in seconds, after an
Ethernet link is established before sending any data over the network. The
valid values are 0 to 255. As an example, a user may need to set a value for
this option if a network protocol, such as Spanning Tree, is enabled on the
switch interface to the client system.
Controls if the TCP Timestamp option is enabled or disabled.
Allows specifying that the iSCSI target drive will appear as the first hard drive
in the system.
Controls the number of connection retries the iSCSI Boot initiator will attempt
if the iSCSI target LUN is busy.
This option specific to IPv6. Toggles between the IPv4 or IPv6 protocol. All IP
settings will be lost when switching from one protocol version to another.
Configuring the iSCSI Target. For information on configuration options, see
iSCSI Protocol and Broadcom Boot Agent Software
Broadcom Boot Agent).
Page 141
