Modifying VLAN
Information
Top-Level Menu
system
ethernet
fddi
display
tokenring
mode
bridge
lowLatency
ip
ipFragmentation
ipx
ipxSnapTranslation
appletalk
trFDDIMode
snmp
addressThreshold
analyzer
agingTime
summary
script
stpState
detail
logout
stpPriority
define
stpMaxAge
modify
stpHelloTIme
remove
stpForwardDelay
stpGroupAddress
srBridgeNumber
port
packetFilter
vlan
To modify VLAN information for a traditional bridge:
1 From the top level of the Administration Console, enter:
bridge vlan modify
You are prompted to reenter the information that defines the VLAN.
Press the Return or Enter key to accept any value that appears in
brackets [ ].
2 Enter the slot number for the bridge.
3 Enter the number of the VLAN interface index.
4 Enter the protocol suite for that VLAN:
DECnet,SNA,Vines,X.25,NetBIOS,default)
5 Enter the VLAN identifier.
6 Enter the VLAN name.
7 Enter the number(s) of the port(s) or
8 If you have selected the IP protocol suite and want to use the Layer 3
address information, enter
if you do not want layer 3 addressing.
undefined
Example:
Select menu option (bridge/vlan):
Select bridge(s) by slot (2-3,5,10-12) [10]:
Select VLAN interface [1-2]:
Protocol Suite (IP,IPX,Apple,XNS,DECnet,SNA,
Vines,X.25,NetBIOS,default):
Integer VLAN Identifier [1]:
VLAN Name [Sales]:
Ports 1=FDDI, 2-17=FastEthernet
Enter port(s)
Layer 3 Address (undefined,defined) [undefined]:
(IP,IPX,Apple,XNS,
.
all
for layer 3 addressing. Enter
defined
modify
2
IP
2
(1-17|all) [1-5]:
Modifying VLAN Information
.
10
D-7
