Defining VLAN
Information for
an HSI Switch
Engine
Top-Level Menu
system
ethernet
fddi
display
tokenring
mode
bridge
lowLatency
ip ipFragmentation
ipx
ipxSnapTranslation
appletalk
trFDDIMode
snmp
addressThreshold
analyzer
agingTime
summary
script stpState
detail
logout
stpPriority
define
stpMaxAge
modify
stpHelloTIme
remove
stpForwardDelay
stpGroupAddress
srBridgeNumber
port
packetFilter
vlan
9 Enter the subnetwork mask.
Example:
menu option (bridge/vlan):
Select bridge(s) by slot (2-3,5,7,9-12) [2]:
Enter Protocol Suite (IP,IPX,Apple,XNS,DECnet,SNA,
Vines,X.25,NetBIOS,default):
Enter Integer VLAN Identifier:
Enter VLAN Name:
Ports 1-2=FDDI, 3-18=Ethernet
Enter port(s)
Layer 3 Address (undefined, defined):
Enter IP Subnet Address:
Enter subnet mask [255.255.0.0]
The maximum number of VLANs you can define on a single bridge is 32.
Follow these steps to create a VLAN definition:
1 From the top level of the Administration Console, enter:
bridge vlan define
2 Enter the slot number for the bridge.
3 Enter the appropriate protocol suite:
DECnet,SNA,Vines,X.25,NetBIOS,default
4 Enter the integer of the VLAN interface identifier.
5 Enter the VLAN name.
6 Enter the number(s) of the port(s) or
the specified slot to the VLAN.
You are prompted to enter the number(s) of the port(s) that can be
assigned to the VLAN.
Defining VLAN Information for an HSI Switch Engine
define
IP
1
SD Marketing
(1-18|all): 1,3-5
158.111.122.0
255.255.255.0
(IP,IPX,Apple,XNS,
all
5
defined
)
to assign all ports on the bridge in
