8-4 C 8: A
HAPTER DMINISTERING
Modifying VLAN
Information
Top-Level Menu
system
ethernet
fddi
display
atm
mode
bridge
ipFragmentation
ip
ipxSnapTranslation
ipx
addressThreshold
appletalk
agingTime
snmp stpState
analyzer
stpPriority
summary
script
stpMaxAge
detail
logout
stpHelloTIme
define
stpForwardDelay
modify
stpGroupAddress
remove
port
packetFilter
vlan
VLAN
S
Example:
Select menu option (bridge/vlan):
Enter Protocol Suite
(IP,IPX,AppleTalk,XNS,DECnet,SNA,Banyan,X.25,NetBIOS,NeBEUI,
IP
default):
Enter VLAN Identifier:
Enter VLAN Name:
Ports 1=FDDI, 2-17=Ethernet
Enter port(s)
Layer 3 Address (undefined, defined):
Enter IP Subnet Address:
Enter subnet mask [255.255.0.0]
The maximum number of VLANs you can define on a single bridge is 32.
To modify VLAN information:
1 From the top level of the Administration Console, enter:
bridge vlan modify
You are prompted to reenter the information that defines the VLAN. Press
the Return or Enter key to accept any value that appears in brackets [ ].
2 Enter the number of the VLAN interface index.
3 Enter the protocol suite for that VLAN:
DECnet, SNA, Banyan, X.25, NetBIOS, NetBEUI, default)
4 Enter the VLAN identifier.
5 Enter the VLAN name.
6 Enter the number(s) of the port(s) or all.
7 If you have selected the IP protocol suite and want to use the Layer 3
address information, enter defined for layer 3 addressing. Enter
undefined if you do not want layer 3 addressing.
1
"SD Marketing"
1-5
(1-17|all):
158.111.122.0
255.255.255.0
(IP, IPX, AppleTalk, XNS,
define
defined
.
