Table
D-1describes these statistics.
Table D-1 Field Attributes for VLAN Information
Field
Description
Index
A system-assigned index used for identifying a particular VLAN
Protocol
The protocol suite of the VLAN
Identifier
A unique, user-defined (4-byte) integer for use by global
management operations
Ports
The numbers of the ports assigned to the VLAN
Name
A 16-byte character string intended to identify the members of the
VLAN
Layer 3
Optional parameters consisting of IP subnetwork and mask used
to set up flood domains for overlapping IP VLAN subnetworks
inPackets
Number of flooded broadcast and multicast packets that were
received on the VLAN
inBytes
Number of flooded broadcast and multicast bytes that were
received on the VLAN
outPackets
Number of flooded broadcast and multicast packets transmitted
over the VLAN
outBytes
Number of flooded broadcast and multicast bytes transmitted over
the VLAN
Displaying VLAN Information
D-3
