Endress+Hauser Proline Promass 40E Technical Information page 31

Proline Promass 40E
Endress+Hauser
Flange according to ASME B16.5, Cl 600: 1.4404 (316/316L)
Order code for "Process connection", option ACS
DN G
³⁄₈" 3.75
½" 3.75
1" 4.88
1½" 6.12
2" 6.50
3" 8.25
All dimensions in [inch]
Tri-Clamp, DIN 11866 line C
di
Dimension in mm (in)
1", 1½", 2" -Tri-Clamp, DIN 11866 line C: 1.4404 (316/316L)
Order code for "Process connection", option FTS
DN Clamp
³⁄₈" 1"
½" 1"
1" 1"
1½" 1½"
2" 2"
3" 3"
3A version, Ra ≤ 32 μin (150 grit): order code for "Process connection", option FTA
3A version, Ra ≤ 16 μin (240 grit): order code for "Process connection", option FTD
All dimensions in [inch]
½"-Tri-Clamp, DIN 11866 line C: 1.4404 (316/316L)
Order code for "Process connection", option FUW
DN Clamp
³⁄₈" ½"
½" ½"
3A version, Ra ≤ 32 μin (150 grit): order code for "Process connection", option FUA
3A version, Ra ≤ 16 μin (240 grit): order code for "Process connection", option FUD
All dimensions in [inch]
L N
10.28 4 × Ø0.62
11.61 4 × Ø0.62
14.96 4 × Ø0.75
19.53 4 × Ø0.88
22.95 4 × Ø0.75
24.46 8 × Ø0.88
E
+1.5 (+0.06)
L
–2.0 (–0.08)
G
1.98
1.98
1.98
1.98
2.52
3.58
G
0.98
0.98
S LK U
0.81 2.62 0.55
0.81 2.62 0.55
0.94 3.50 0.96
1.13 4.50 1.50
1.25 5.00 1.94
1.50 6.62 2.90
L U
9.02 0.87
10.75 0.87
12.76 0.87
17.95 1.37
22.13 1.87
26.46 2.87
L U
9.02 0.37
10.75 0.37
di
0.21
0.33
0.47
0.69
1.02
1.59
A0021287
di
0.21
0.33
0.47
0.69
1.02
1.59
di
0.21
0.33
31
