Endress+Hauser Proline Promass 40E Technical Information page 26

26
DIN 11864-1 Form A, thread, DIN11866 line A
di
Dimension unit in mm (in)
DIN 11864-1 Form A, thread, DIN11866 line A: 1.4404 (316/316L)
Order code for "Process connection", option FLW
DN
8 Rd 28 × ¹⁄₈"
15 Rd 34 × ¹⁄₈"
25 Rd 52 × ¹⁄₆"
40 Rd 65 × ¹⁄₆"
50 Rd 78 × ¹⁄₆"
80 Rd 110 × ¹⁄₄"
3A version, Ra ≤ 0.8 μm (150 grit): order code for "Process connection", option FLA
All dimensions in [mm]
E
+1.5 (+0.06)
L
–2.0 (–0.08)
G L
229
273
324
456
562
672
Proline Promass 40E
A0021289
U di
10 5.35
16 8.30
26 12.00
38 17.60
50 26.00
81 40.5
