DIN 11851, thread, DIN11866 line A
di
Dimension in mm (in)
DIN 11851, thread, DIN11866 line A: 1.4404 (316/316L)
Order code for "Process connection", option FMW
DN
8 Rd 34 × ¹⁄₈"
15 Rd 34 × ¹⁄₈"
25 Rd 52 × ¹⁄₆"
40 Rd 65 × ¹⁄₆"
50 Rd 78 × ¹⁄₆"
80 Rd 110 × ¹⁄₄"
3A version, Ra ≤ 0.8 μm (150 grit): order code for "Process connection", option FMA
All dimensions in [mm]
E
+1.5 (+0.06)
L
–2.0 (–0.08)
G L
229
273
324
456
562
672
A0021288
U di
16 5.35
16 8.30
26 12.0
38 17.6
50 26.0
81 40.5
