Endress+Hauser Proline Promass 40E Technical Information page 22

22
Flange connections ASME B16.5
Flange according to ASME B16.5, Cl 150: 1.4404 (F316/F316L)
Order code for "Process connection", option AAS
DN G
8 88.9
15 88.9
25 108.0
40 127.0
50 152.4
80 190.5
All dimensions in [mm]
Flange according to ASME B16.5, Cl 300: 1.4404 (F316/F316L)
Order code for "Process connection", option ABS
DN G
8 95.2
15 95.2
25 123.9
40 155.4
50 165.1
80 209.5
All dimensions in [mm]
Flange according to ASME B16.5, Cl 600: 1.4404 (F316/F316L)
Order code for "Process connection", option ACS
DN G
8 95.3
15 95.3
25 124.0
40 155.4
50 165.1
80 209.6
All dimensions in [mm]
L N
232 4 × Ø15.7
279 4 × Ø15.7
329 4 × Ø15.7
445 4 × Ø15.7
556 4 × Ø19.1
610 4 × Ø19.1
L N
232 4 × Ø15.7
279 4 × Ø15.7
329 4 × Ø19.0
445 4 × Ø22.3
556 8 × Ø19.0
610 8 × Ø22.3
L N
261 4 × Ø15.7
295 4 × Ø15.7
380 4 × Ø19.1
496 4 × Ø22.4
583 8 × Ø19.1
672 8 × Ø22.4
Proline Promass 40E
S LK U
11.2 60.5 15.7
11.2 60.5 15.7
14.2 79.2 26.7
17.5 98.6 40.9
19.1 120.7 52.6
23.9 152.4 78.0
S LK U
14.2 66.5 15.7
14.2 66.5 15.7
17.5 88.9 26.7
20.6 114.3 40.9
22.3 127.0 52.6
28.4 168.1 78.0
S LK U
20.6 66.5 13.9
20.6 66.5 13.9
23.9 88.9 24.3
28.7 114.3 38.1
31.8 127.0 49.2
38.2 168.1 73.7
Endress+Hauser
di
5.35
8.30
12.0
17.6
26.0
40.5
di
5.35
8.30
12.0
17.6
26.0
40.5
di
5.35
8.30
12.0
17.6
26.0
40.5
