DIN 11864-2 Form A, flange, DIN11866 line A, flange with notch
di
Dimension unit in mm (in)
DIN 11864-2 Form A, flange, DIN11866 line A, flange with notch: 1.4404 (316/316L)
Order code for "Process connection", option FKW
DN G
8 54
15 59
25 70
40 82
50 94
80 133
3A version, Ra ≤ 0.8 μm (150 grit): order code for "Process connection", option FKA
All dimensions in [mm]
E
+1.5 (+0.06)
L
–2.0 (–0.08)
L N S
249 4 × Ø9 10
293 4 × Ø9 10
344 4 × Ø9 10
456 4 × Ø9 10
562 4 × Ø9 10
672 8 × Ø11 12
A
A
S
LK U
37 10
42 16
53 26
65 38
77 50
112 81
A0021294
di
5.35
8.30
12.0
17.6
26.0
40.5
