Proline Promass 40E
Endress+Hauser
Flange according to EN 1092-1 (DIN 2501), PN 63: 1.4404 (F316/F316L)
Order code for "Process connection", option D3S
Flange with groove according to EN 1092-1 (DIN 2512N), PN 63: 1.4404 (F316/F316L)
Order code for "Process connection", option D7S
Surface roughness (flange): EN 1092-1 Form B2 (DIN 2526 Form E), Ra 0.8 to 3.2 μm
DN G
50 180
80 215
All dimensions in [mm]
Flange EN 1092-1 (DIN 2501), PN 100: 1.4404 (F316/F316L)
Order code for "Process connection", option D4S
Flange with groove according to EN 1092-1 (DIN 2512N), PN 100: 1.4404 (F316/F316L)
Order code for "Process connection", option D8S
Surface roughness (flange): EN 1092-1 Form B2 (DIN 2526 Form E), Ra 0.8 to 3.2 μm
DN G
8 105
15 105
25 140
40 170
50 195
80 230
All dimensions in [mm]
L N S
565 4 × Ø22 26
650 8 × Ø22 28
L N S
261 4 × Ø14 20
295 4 × Ø14 20
360 4 × Ø18 24
486 4 × Ø22 26
581 4 × Ø26 28
660 8 × Ø26 32
LK U di
135 54.5 26.0
170 81.7 40.5
LK U di
75 17.3 5.35
75 17.3 8.30
100 28.5 12.0
125 42.5 17.6
145 53.9 26.0
180 80.9 40.5
