Endress+Hauser Proline Promass 40E Technical Information page 24

24
Tri-Clamp, DIN 11866 line C
di
Dimension in mm (in)
1", 1½", 2" -Tri-Clamp, DIN 11866 line C: 1.4404 (316/316L)
Order code for "Process connection", option FTS
DN Clamp
8 1"
15 1"
25 1"
40 1½"
50 2"
80 3"
3A version, Ra ≤ 0.8 μm (150 grit): order code for "Process connection", option FTA
3A version, Ra ≤ 0.4 μm (240 grit): order code for "Process connection", option FTD
All dimensions in [mm]
½"-Tri-Clamp, DIN 11866 line C: 1.4404 (316/316L)
Order code for "Process connection", option FUW
DN Clamp
8 ½"
15 ½"
3A version, Ra ≤ 0.8 μm (150 grit): order code for "Process connection", option FUA
3A version, Ra ≤ 0.4 μm (240 grit): order code for "Process connection", option FUD
All dimensions in [mm]
E
+1.5 (+0.06)
L
–2.0 (–0.08)
G L
50.4 229
50.4 273
50.4 324
50.4 456
63.9 562
90.9 672
G L
25.0 229
25.0 273
Proline Promass 40E
A0021287
U di
22.1 5.35
22.1 8.30
22.1 12.0
34.8 17.6
47.5 26.0
72.9 40.5
U di
9.5 5.35
9.5 8.30
