Flange connections JIS
JIS B2220, flange, 10K: 1.4404 (F316/F316L)
Order code for "Process connection", option NDS
DN G
50 155
80 185
All dimensions in [mm]
JIS B2220, flange, 20K: 1.4404 (F316/F316L)
Order code for "Process connection", option NES
DN G
8 95
15 95
25 125
40 140
50 155
80 200
All dimensions in [mm]
JIS B2220, flange, 40K: 1.4404 (F316/F316L)
Order code for "Process connection", option NGS
DN G
8 115
15 115
25 130
40 160
50 165
80 210
All dimensions in [mm]
JIS B2220, flange, 63K: 1.4404 (F316/F316L)
Order code for "Process connection", option NHS
DN G
8 120
15 120
25 140
40 175
50 185
80 230
All dimensions in [mm]
L N
556 4 × Ø19 16
605 8 × Ø19 18
L N
232 4 × Ø15 14
279 4 × Ø15 14
329 4 × Ø19 16
445 4 × Ø19 18
556 8 × Ø19 18
605 8 × Ø23 22
L N
261 4 × Ø19 20
300 4 × Ø19 20
375 4 × Ø19 22
496 4 × Ø23 24
601 8 × Ø19 26
662 8 × Ø23 32
L N
282 4 × Ø19 23
315 4 × Ø19 23
383 4 × Ø23 27
515 4 × Ø25 32
616 8 × Ø23 34
687 8 × Ø25 40
S LK U
120 50
150 80
S LK U
70 15
70 15
90 25
105 40
120 50
160 80
S LK U
80 15
80 15
95 25
120 38
130 50
170 75
S LK U
85 12
85 12
100 22
130 35
145 48
185 73
di
26.0
40.5
di
5.35
8.30
12.0
17.6
26.0
40.5
di
5.35
8.30
12.0
17.6
26.0
40.5
di
5.35
8.30
12.0
17.6
26.0
40.5
