Endress+Hauser Proline Promass 40E Technical Information page 30

30
Process connections in US units
Flange connections ASME B16.5
di
Dimension unit in mm (in)
Flange according to ASME B16.5, Cl 150: 1.4404 (316/316L)
Order code for "Process connection", option AAS
DN G
³⁄₈" 3.50
½" 3.50
1" 4.25
1½" 5.00
2" 6.00
3" 7.50
All dimensions in [inch]
Flange according to ASME B16.5, Cl 300: 1.4404 (316/316L)
Order code for "Process connection", option ABS
DN G
³⁄₈" 3.75
½" 3.75
1" 4.88
1½" 6.12
2" 6.50
3" 8.25
All dimensions in [inch]
E
+1.5 (+0.06)
L
– 2.0 (–0.08)
L N
9.13 4 × Ø0.62
10.98 4 × Ø0.62
12.95 4 × Ø0.62
17.52 4 × Ø0.62
21.89 4 × Ø0.75
24.02 4 × Ø0.75
L N
9.13 4 × Ø0.62
10.98 4 × Ø0.62
12.95 4 × Ø0.75
17.52 4 × Ø0.88
21.89 4 × Ø0.75
24.02 8 × Ø0.88
Proline Promass 40E
S
S LK U
0.44 2.38 0.62
0.44 2.38 0.62
0.56 3.12 1.05
0.69 3.88 1.61
0.75 4.75 2.07
0.94 6.00 3.07
S LK U
0.56 2.62 0.62
0.56 2.62 0.62
0.69 3.50 1.05
0.81 4.50 1.61
0.88 5.00 2.07
1.12 6.62 3.07
Endress+Hauser
A0021285
di
0.21
0.33
0.47
0.69
1.02
1.59
di
0.21
0.33
0.47
0.69
1.02
1.59
