1.6

Specifications

LCD Panel
Display Type
Max. Resolution
Brightness
Color
Pixel Pitch
Viewing Angle
Contrast
Backlight Lifetime
Touchscreen Type
Light Transmission
Controller
Durability
CPU
Memory
Storage
Network (LAN)
I/O
Expansion
PPC-3100/3120 User Manual

Figure 1.4 PPC-3120-RE9A Dimensions

PPC-3100-RE9A
10.4"
TFT LCD
800 x 600
400
262k/16.2M
0.264 (H) x 0.264 (V)
160, 140
5000
30,000 hrs (minimum)
5-wire resistive touch
80±5%
USB interface
At least 35 million touches without failure
Intel® Atom™ E3940 quad-core
1 x SODIMM DDR3L 1866 MHz (max. 8 GB)
1 x 2.5" SATA bay
1 x mSATA bay
2 x 10/100/1000 Mbps Ethernet
5 x Serial ports: 4 x RS-232 and 1 x isolated RS-422/485 (configu-
rable via the BIOS system)
4 x USB 3.0
1 x Line-out, 1 x Mic-in
1 x VGA
1 x HDMI
1 x GPIO (8 channels, TTL level, internal)
1 x Mini PCIe
Optional: 1 x PCIe x1 or 1 x PCI (for PPC-3120)
4
PPC-3120-RE9A
12.1"
TFT LCD
1024 x 768
600
262k/16.2M
0.240 (H) x 0.240 (V)
160, 140
700
50,000 hrs (minimum)
