Product Disassembly Instructions
Product Category:
Panel PC
Product Marketing Name / Model:
PPC-3120-RE9A
Purpose:
The document provides the basic instructions for the disassembly of products to remove components and
materials requiring selective treatment, as defined by EU directive 2002/96/EC and 2012/19/EU, Waste Electrical and
Electronic Equipment (WEEE).
1.0
Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
Item Description
Printed Circuit Boards (PCB) or Printed
Circuit Assemblies (PCA)
Batteries
External electrical cables and Power
cord
Liquid Crystal Displays (LCD) with a
surface greater than 100 sq cm
Cathode Ray Tubes (CRT)
Gas Discharge Lamps
Electrolytic Capacitors / Condensers
measuring greater than 2.5 cm in
diameter or height
Notes
With a surface greater than 10 sq. cm Mother
board, Card Reader board, USB Daughter
board, LID Daughter board
All types including standard alkaline and
lithium coin or button style batteries 6cell
battery or 9 cell battery, and RTC battery
Includes background illuminated displays with
gas discharge lamps
Quantity of items
included in product
7
1
0
1
0
0
0
