7.3. Kvs - values in m ³ /h
DN40
stroke
15 mm
Kvs S Ø
25
38
16
10
26
6,3
4,0
13
2,5
1,5"
stroke
15 mm
Kvs S Ø
25
38
16
10
26
6,3
4,0
13
2,5
kvs = values in m³/h
S Ø = seat diameter in mm
11
7.

Technical Data

DN 50
stroke
15 mm
Kvs S Ø Kvs
40 50 63
25 40
38
16
10 25
26
6,3 16
2"
stroke
15 mm
Kvs S Ø Kvs
40 50 63
25 40
38
16
10 25
26
6,3 16
DN 65 DN 80
stroke stroke
15 mm 15 mm
S Ø Kvs
66 100
50 63
40
38
2,5"
stroke stroke
15 mm 15 mm
S Ø Kvs
66 80
50 63
40
38
DN 100
stroke
15 mm
S Ø Kvs
81 160
66 100
50 63
3" 4"
stroke
15 mm
S Ø Kvs
72,9 160
66 100
50 63
Modulating valve with product diaphragm
DELTA RGMS4 - MFS + MFH 3A
Instruction manual: rev. 1
UK
S Ø
100
81
66
S Ø
100
81
66
