Remove Extender From Command Center - Landis+Gyr Gridstream RF Series IV Installation And User Manual

Chapter 4 - Extender Configuration in Command Center
History Tab
The History Tab, shown in Figure 4 - 12, provides a list of the events and errors that have been
logged by this Extender.

Remove Extender from Command Center

This function allows the user to remove a deployed Extender from service. The removed Extender
can either be put back into inventory or archived.
1. From Command Center, select Operations > Endpoints. The Endpoint/Meter Selection
window will open.
2. Enter the Extender serial number in the Endpoint field.
3. Click GO. The Available Tasks list will appear.
4. From the Available Tasks, select the Remove Endpoint from Service link. The Remove
Endpoint From Service window will open.
38
Figure 4 - 12. Extender History tab
Figure 4 - 13. Endpoint Meter/Selection Available Tasks
98-1178 Rev AA
Landis+Gyr
Installation and User Guide
