Create An Import Installation File - Landis+Gyr Gridstream RF Series IV Installation And User Manual

Landis+Gyr

Create an Import Installation File

Following is the procedure to create An Import Installation File.
1. From Command Center home, select Operations > Import > Import Installation File.
The Import Installation File window will open.
2. Click the CSV Template link.
3. Select Save and designate the file location.
4. Open up the saved .CSV file with Microsoft Excel.
5. Fill in the columns with the appropriate data. Each row in the document represents one Extender
(or Endpoint) and should only contain data related to that specific unit.
CSV File Fields
Data
User ID*
Installation Date*
Installation Time*
Change Out meter number
Change Out meter kWh
Installation and User Guide
Chapter 4 - Extender Configuration in Command Center
Figure 4 - 3. Import Installation Window
Table 4-1.
Format
AlphaNum (30)
Date
MM/DD/YYYY
12/26/2009
Time HHMM AM/PM
11:12 AM
AlphaNum (20)
AlphaNum (20)
98-1178 Rev AA
Format/Description
Login assigned by the utility for the installer.
Utility may elect to use "1" for System usage
Actual date the meter was installed. This date is
used in various Command Center reports to
track deployment statistics.
Actual time the meter was installed. This date is
used in various Command Center Reports to
track deployment statistics.
The meter being replaced with a new meter.
Meter change out information is displayed in the
notes section of the endpoint information screen.
The kWh reading on the meter being replaced
Meter change out kWh information is displayed
in the notes section of the endpoint information
screen. Variable Character
31
