Monitor and control equipment

You can monitor and control equipment from:
•
The equipment's points shown under Properties (page 31)
•
The equipment graphic (page 28) (if the device has an equipment graphic)
• The equipment's CCN tables (page 43)
If a point's value is editable, changing the value sends the new value only to the device.
If the point has a Force checkbox, you can force the value to a new value that you specify. The new value is
sent to the device. Forced values are indicated in the graphics by a dashed yellow line.

To view an equipment's CCN tables

In the navigation tree, select the equipment.
1
Click
2
Select the table you want to view.
3

To force a CCN point value

You can force certain editable point values to a specified setting:
•
In the equipment's tables - to see tables, click
•
From a graphic - hold down Ctrl key on your keyboard and, using your mouse, click on the point value on
the graphic. A Properties dialog will be displayed.
Forced values are indicated by a dashed yellow line on graphics.
Select the Force checkbox.
1
Type the value you want to send to the device.
2
Click OK or Apply.
3
i-Vu CCN Pro 4.2
next to the equipment to expand it.
next to the equipment
Monitor and control equipment
43
