Zone Manager
NEW
40KMC---N
42HMC---N
42VMC---N
40SMC---N
OWNER'S MANUAL

Advertisement

loading

Related Manuals for Carrier Zone Manager

Summary of Contents for Carrier Zone Manager

  • Page 1 Zone Manager 40KMC---N 42HMC---N 42VMC---N 40SMC---N OWNER’S MANUAL...
  • Page 2 Zone Manager Owner's manual This control system only operates with indoor units of the following models: 42HMC---N Hi-Wall, 42VMC---N Console & Underceiling, 40SMC---N Satellite and 40KMC---N Cassette. For installation instructions of this unit, refer to the relevant manuals. Contents Page General information ..................

  • Page 3: Period

    Open panel 1: the internal keyboard has 9 buttons 8 of which have double functions. • Make sure the Zone Manager control unit has not been damaged in transport; if the opposite is true file an immediate • Normal function buttons claim with the shipping company.

  • Page 4: Period

    Zone Manager Characteristics and switching on E N G L I S H Example of normal operating Control display with panel open Key to abbreviations of the days of the week MO = Mondey = Tuesday WE = Wednesday = Thursday...
  • Page 5 " word blinks on the display for 15". TIME down • Press the "up" or "down" button. The time will be displayed in one of the following modes (consult the Zone Manager installation manual): - 12 hours with AM = morning, PM = Afternoon - 24 hours The time goes forwards or backwards by one minute at a time.
  • Page 6 The temperature, fan speed and louver operating mode indications disappear from the display. NOTE: If the temperature sensor in the Zone Manager is "ON", the room air temperature will be displayed and the Setpoint disappear from the display. Your system will heat or cool as needed to reach your AUTO desired temperature.
  • Page 7 Zone Manager Normal operation Button to display the operating modes of each zone • Press the " " button. NEXT ZONE The successive zone is selected on the display with the relative operating parameters. EXAMPLE: Zone 1: - MODE: Zone 2:...

  • Page 8: Period

    E N G L I S H Access to programming IMPORTANT: Before you program your Zone Manager, take a moment to plan you temperature schedule. Each day of the week is divided into four time periods: 1, 2, 3, and 4. For each time period, enter a start time and a setpoint in the appropriate block.
  • Page 9 Zone Manager System programming Programming zone periods WARNING: Each zone can have a maximum of 4 periods. • Press the " " button. PROGRAM " 1" and " 1" are first displayed for the current day. ZONE PERIOD The current time programmed for that period will flash indicating a change can be mode if desired.
  • Page 10 Zone Manager System programming E N G L I S H Operation mode programming • Press the " " button. PROGRAM • Press the " " button to select the day to program. NEXT DAY • Press the " " button.
  • Page 11 Zone Manager System programming EXAMPLE: We want to copy the setpoints of zone 1 into zone 2 or a zone successive to it. • Press the " " button. PROGRAM Zone 1 with the time blinking appears on the display.
  • Page 12 Zone Manager Example of general programming E N G L I S H Access to programming: - Press " ". PROGRAM Setting the mode, fan speed, and air flow: - Press " " and select " ". MODE AUTO - Press "...

  • Page 13: System Override

    The display returns to the programmed setpoint and the " " HOLD logo disappear. HOLD FUNCTION EXAMPLE 1: 8:00 10:00 3:00 5:00 If a Zone Manager is in an OFF period. ON Period OFF Period ON Period OFF Period Schedule: Setpoint = 23 ° C 8:00 AM ON Period Set point 26°C...
  • Page 14 Zone Manager System override E N G L I S H HOLD FUNCTION: EXAMPLE 2 8:00 10:00 3:00 5:00 Deadband = 16 ° C ON Period SB Period ON Period OFF Period Schedule: Setpoint = 23 ° C Set point 26°C...

  • Page 15: System Override

    Zone Manager System override If the " " button NEXT ZONE is pressed to see the zone 2 settings, the display remains blocked on zone 1. All zones will continue to follow the parameters of zone 1. For to change the value of temperature: down •...
  • Page 16 Zone Manager Example of general programming E N G L I S H Example of general programming PERIOD 1 PERIOD 2 PERIOD 3 PERIOD 4 Time / Setpoint / Mode Time / Setpoint / Mode Time / Setpoint / Mode...
  • Page 17 L010125H81 - 1102 Via R. Sanzio, 9 - 20058 Villasanta (MI) Italy - Tel. 039/3636.1 The manufacturer reserves the right to change any product specifications without notice. Order No. 18192-74, November 2002. Supersedes Order No. (new) Printed in Italy...
