Table 2: Termination Details
Type of Field Device
Feedback from
EPP-1000
Dry Contact (Binary
Input)
0–10 VDC Output to
Actuator (External
Source)
0–10 VDC Output to
Actuator (Internal
Source)
4–20 mA Output to
Actuator
FEC26 Field Equipment Controllers Installation Instructions
Type of
Termination Diagrams
Input/Output
UI
UI or BI
CO or AO
CO or AO
CO or AO
9
