FEC16 Extended Temperature Field Equipment Controller
Installation Instructions
MS-FEC1611-0ET, MS-FEC1611-1ET
Applications
The FEC16 extended temperature field controller is
part of the Metasys® system Field Equipment
Controller (FEC) family. The FEC16 controller runs
pre-engineered and user-programmed applications
and provides the inputs and outputs required to monitor
and control a wide variety of Heating, Ventilating, and
Air Conditioning (HVAC) equipment.
FEC extended temperature controllers operate on an
RS-485 BACnet® Master-Slave/Token-Passing (MS/
TP) Bus as BACnet Application Specific Controllers (B-
ASC) and integrate into the Web-based Metasys
system.
IMPORTANT: In Metasys system smoke control
applications, use only the MS-FEU1610-0U model
that is UL/cUL Listed, UUKL 864 Listed, 9th Edition
Smoke Control Equipment. For Metasys system
smoke control applications, you must refer to the
Metasys® System UL 864 9th Edition UUKL/ORD-
C100-13 UUKLC Smoke Control System Technical
Bulletin (LIT-12011252) for detailed requirements
and procedures for installing and operating UUKL
864 Listed Metasys system devices. Failure to meet
the requirements or follow the procedures in the
Metasys® System UL 864 9th Edition UUKL/ORD-
C100-13 UUKLC Smoke Control System Technical
Bulletin (LIT-12011252) can void the UUKL 864
listing for Smoke Control Equipment.
FEC16 Extended Temperature Field Equipment Controller Installation Instructions
Part No. 24-10143-306, Rev. C
Supersedes November 13, 2013
North American Emissions Compliance
Canada
This Class (A) digital apparatus meets all the
requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la Classe (A) respecte
toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
United States
This equipment has been tested and found to
comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when this equipment is
operated in a commercial environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area
may cause harmful interference, in which case the
users will be required to correct the interference at
their own expense.
Installation
Observe these guidelines when installing an FEC
extended temperature controller:
•
Transport the FEC in the original container to
minimize vibration and shock damage.
•
Verify that all parts shipped with the FEC.
•
Do not drop the FEC or subject it to physical shock.
Issued May 16, 2014
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Johnson Controls FEC16 Series
Summary of Contents for Johnson Controls FEC16 Series
- Page 1 FEC16 Extended Temperature Field Equipment Controller Installation Instructions Part No. 24-10143-306, Rev. C MS-FEC1611-0ET, MS-FEC1611-1ET Issued May 16, 2014 Supersedes November 13, 2013 Applications North American Emissions Compliance The FEC16 extended temperature field controller is Canada part of the Metasys® system Field Equipment Controller (FEC) family.
-
