FEU2610 Field Equipment Controller
Installation Instructions
MS-FEU2610-0U
Applications
The MS-FEU2610-0U controller is a member of the Metasys® system Field Equipment Controller (FEC) family.
The FEU26 is designed to run a variety of pre-engineered or user-programmed Heating, Ventilating, and Air
Conditioning (HVAC) applications, and provides the inputs/outputs required for these applications.
IMPORTANT: The MS-FEU2610-0U controller is used in Metasys Release 8.1 smoke control applications and
is UL 864 UUKL/UUKLC 10th Edition Smoke Control Listed. You must refer to the Metasys® System UL 864
10th Edition UUKL/ORD-C100-13 UUKLC Smoke Control System (LIT-12012487) for detailed requirements and
procedures for installing, commissioning, and operating all UL 864 UUKL/UUKLC Listed Metasys system
devices. The UL 864 UUKL/UUKLC listing for Smoke Control Equipment is voided if (1) you do not use the
required software tools at the required versions; or (2) you do not meet the requirements or do not follow the
procedures as documented in the Metasys® System UL 864 10th Edition UUKL/ORD-C100-13 UUKLC Smoke
Control System (LIT-12012487).
North American Emissions Compliance
Canada
This Class (A) digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la Classe (A) respecte toutes les exigences du Règlement sur le matériel brouilleur
du Canada.
United States
This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when this equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be required to correct the interference at his/her
own expense.
FEU2610 Field Equipment Controller Installation Instructions
(barcode for factory use only)
Part No. 24-10143-543, Rev. B
1
Release 8.1
Issued March 2018
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Johnson Controls FEU2610 Series
Summary of Contents for Johnson Controls FEU2610 Series
- Page 1 (barcode for factory use only) FEU2610 Field Equipment Controller Installation Instructions MS-FEU2610-0U Part No. 24-10143-543, Rev. B Release 8.1 Issued March 2018 Applications The MS-FEU2610-0U controller is a member of the Metasys® system Field Equipment Controller (FEC) family. The FEU26 is designed to run a variety of pre-engineered or user-programmed Heating, Ventilating, and Air Conditioning (HVAC) applications, and provides the inputs/outputs required for these applications.
- Page 2 Figure 1: FEU2610 Controller Physical Features and Wiring Terminals FEU2610 Field Equipment Controller Installation Instructions...
-
Page 3: Parts Included
nstallation Observe these guidelines when installing the FEU26: • Transport the FEU in the original container to minimize vibration and shock damage to the FEU. • Verify that all parts shipped with the FEU. • Do not drop the FEU or subject it to physical shock. Parts Included •... -
Page 4: Wall Mount Applications
Wall Mount Applications To mount the FEU26 on a wall (or other vertical surface): 1. Ensure that all three mounting clips are pulled outward and snapped firmly into the extended position. See Figure 2 Figure 2: DIN Rail and Mounting Clip Features on the Back of an FEU26, mm (in.) 1-7/8 3-1/2 3-1/2... -
Page 5: Din Rail Mount Applications
DIN Rail Mount Applications To mount the FEU26 on a DIN rail: 1. Securely mount a 20.3 cm (8 in.) (or longer) section of DIN rail horizontally and centered in the required space. Figure 4: Required Orientation for DIN Rail Mount Applications 2. -
Page 6: Hard-Wired Installation
Wiring Observe the following guideline when wiring a controller: Electric Shock:Disconnect the power supply before making electrical connections to avoid electric shock. Mise En Garde: Risque de décharge électrique: Débrancher l'alimentation avant de réaliser tout raccordement électrique afin d'éviter tout risque de décharge électrique. For information on the MS/TP Bus, refer to the MS/TP Communications Bus Technical Bulletin (LIT-12011034). -
Page 7: Power Wiring
Figure 8: 24 VAC Supply Power Terminal Block Wiring Supply Power Terminal Block 24V~ Supply Power Terminal Block Plug Wires from Johnson Controls 24 VAC, Class 2 Power Transformer Brown Wire Orange Wire (COM) (24 VAC) FEU2610 Field Equipment Controller Installation Instructions... - Page 8 <30 m (90 ft) Internal 12 V, 15k ohm Pullup (Row A in Table RTD (1k Nickel [Johnson Controls], 1k Platinum, A99B Silicon Temperature Sensor) Negative Temperature Coefficient (NTC) Sensor (10k Type L, 2.252k Type 2) Binary Input, Dry Contact Maintained Mode 0.6 mm (22 AWG) stranded, 2-wire...
- Page 9 Table 1: Field Controller Platform Wiring List (Part 2 of 3) Terminal Terminal Function and Electrical Ratings/Requirements Recommended Cable Type Block Labels and Length Analog OUT OUT n Analog Output, Voltage Mode 0.6 mm (22 AWG) stranded, 2-wire twisted, non-shielded cable for Sources 0-10 VDC output voltage runs of <30 m (90 ft) External 1k ohm minimum load required...
- Page 10 Table 1: Field Controller Platform Wiring List (Part 3 of 3) Terminal Terminal Function and Electrical Ratings/Requirements Recommended Cable Type Block Labels and Length Provides SA Bus communication network. 0.6 mm (22 AWG) stranded, 4-wire SA Bus twisted, shielded cable recommended Provides reference for network communication bus and 15 VDC source power.
-
Page 11: Setup And Adjustments
Wiring Requirements to determine the maximum wire length allowable when alternative wire gauges are required. Figure 9 Figure 9: Maximum Wire Length by Current and Wire Size Setup and Adjustments Determining the FC Bus Address The FC Bus address switch sets a unique address for this controller on the FC Bus. You must set the FEU’s device address for your field bus application. -
Page 12: Setting The Jumpers
Setting the FC Bus Address Set the address of the FEU26 using the DIP switches on the face of the FEU26. The address equals the sum of the numbers set to ON. For example, if the first (1), the third (4), and the fifth (16) DIP switches are set to ON, the device address is 21 (1 + 4 + 16 = 21). -
Page 13: Troubleshooting
Table 4: Jumper Labels and UI Inputs (Part 2 of 2) Jumper Position Universal Input (UI) When set to the INT position, the FEU26 is the power source for the Binary Output and both sides of the load can be wired directly to the OUTx and COMx terminals. Setting the jumper to the EXT position isolates the Binary Outputs, and power must come from one or more external sources. -
Page 14: Repair Information
On Steady = Communication lost, waiting to join communication ring Repair Information The MS-FEU2610-0U model is UL 864 10th Edition UUKL/ORD-C100-13 UUKLC listed for smoke control. If the device fails to operate within its specifications, contact the Johnson Controls Repair Center in Louisville, Kentucky, at 1-502-671-7312. Accessories to order accessories. - Page 15 The performance specifications are nominal and conform to acceptable industry standard. For application at conditions beyond these specifications, consult the local Johnson Controls® office. Johnson Controls shall not be liable for damages resulting from misapplication or misuse of its products.
