4.1 List of duct distribution system spare
parts
Attention:
•
use liquid Tefl on guaranteed for water pressures up to 100 bars to seal
the water connections;
•
wait 3 hours for the Tefl on to set.
63
77
69
67
61
64
69
76
79
0
73
Fig. 4.b
.

4. RACK SPARE PARTS

66
62
Fig. 4.a
74 75
1 2
78
Ref. Description
65
60 "L" profi le
61 "C" side profi le
62 vertical manifold support bar 98C657P1**
63 horizontal manifold
64 vertical manifold
60
65 G1/4" M/F elbow connector 1309610AXX
66 G1/8" hose
67 stainless steel solenoid valve
24 V 50 Hz NC
69 stainless steel solenoid valve
72
24 V 50 Hz NA
72 distributor support bracket
61
74 MTP1 atomising nozzle 2.8
kg/h marked "1"
75 MTP2 atomising nozzle 4.0
kg/h marked "2"
76 kit of 8 brackets
77 kit for assembly of a vertical
77
manifold with screws and
washers
78 1/8" M NPT plug
79 MTP1 atomising nozzle 1.5
60
kg/h
kit of fl anged M6 screws for
assembling complete frame
11 "humiFog multizone - spare parts" +0300068IE - rel. 1.0 - 15.01.2014
ENG
P/N Notes
98C733P** ** = length in relation to
98C657P1**
the number of 3 -18 m
modules
98C733P4**
98C585P2**
14C531A097
1312110AXX
1312107AXX new P/N (previous P/N)
(1312115AXX) perfectly
interchangeable
14C733A097
UAKMTP1000
UAKMTP2000
UAKS000000
UAKMOR0000
1309639AXX
UAKMTP0000
UAKVITIM60
Tab. 4.a
