HARDWARE INSTALLATION GUIDE
ExtremeSwitching CES 2000 Series and
ExtremeRouting CER 2000 Series
Hardware Installation Guide
9035631-01
November 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ExtremeSwitching CES 2000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Extreme Networks ExtremeSwitching CES 2000 Series

Summary of Contents for Extreme Networks ExtremeSwitching CES 2000 Series

  • Page 1 HARDWARE INSTALLATION GUIDE ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01 November 2018...
  • Page 2 Legal Notice Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.

  • Page 3: Table Of Contents

    Control features.............................................. 27 Network interfaces............................................31 Power supplies..............................................32 Cooling system and fans..........................................33 Connecting to a Network Device ....................................35 Password assignment............................................35 IP address configuration............................................36 Support of sub-net masks.........................................36 ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 4 Operating environment ............................................71 Storage environment ............................................71 Cooling..................................................71 Safety agency approvals............................................72 Electromagnetic approvals..........................................72 Port specifications..............................................72 Console port pin assignments......................................... 73 Management port pin assignments....................................... 73 ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 5 General cautions.............................................99 Electrical cautions............................................100 Cautions related to equipment weight....................................104 Danger Notices..............................................104 General dangers............................................104 Electrical dangers............................................105 Dangers related to equipment weight....................................107 Laser dangers.............................................. 108 ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 6 ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 7: Preface

    Getting Help..........................................9 • Providing Feedback to Us....................................9 ® This section discusses the conventions used in this guide, ways to provide feedback, additional help, and other Extreme Networks publications. Conventions This section discusses the conventions used in this guide. Notes, cautions, and warnings Notes, cautions, and warning statements may be used in this document.

  • Page 8: Command Syntax Conventions

    Some software files have been licensed under certain open source licenses. More information is available at: www.extremenetworks.com/ support/policies/open-source-declaration/. Training Extreme Networks offers product training courses, both online and in person, as well as specialized certifications. For more information, visit www.extremenetworks.com/education/. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 9: Getting Help

    Providing Feedback to Us Quality is our first concern at Extreme Networks, and we have made every effort to ensure the accuracy and completeness of this document. We are always striving to improve our documentation and help you work better, so we want to hear from you! We welcome all feedback but especially want to know about: •...
  • Page 10 Please provide the publication title, part number, and as much detail as possible, including the topic heading and page number if applicable, as well as your suggestions for improvement. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 11: About This Document

    This document is designed for system administrators with a working knowledge of Layer 2 and Layer 3 switching and routing. If you are using an Extreme Networks device, you should be familiar with the following protocols if applicable to your network - IP, RIP, OSPF, BGP, ISIS, IGMP, PIM, MPLS, and VRRP.

  • Page 12: How Command Information Is Presented In This Guide

    6.3.00 are included in release 6.3.00a. On October 30, 2017, Extreme Networks, Inc. acquired the data center networking business from Brocade Communications Systems, Inc. This document has been updated to remove or replace references to Brocade Communications, Inc. with Extreme Networks., Inc., as appropriate.

  • Page 13: Product Overview

    In order to meet these challenges, the ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series were purpose-built to offer flexible, secure and advanced processing capabilities in a compact form factor. The CES Series 2000 and CER 2000 Series are compact 1 RU, multi-service edge or aggregation devices with a powerful set of capabilities chosen to combine performance with rich functionality at the edge of the network.
  • Page 14 Introduction FIGURE 1 CES 2000 Series 2024C-4X FIGURE 2 CES 2000 Series 2024F-4X FIGURE 3 CES 2000 Series 2024C ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 15 Introduction FIGURE 4 CES 2000 Series 2024F FIGURE 5 CES 2000 Series 2048C FIGURE 6 CES 2000 Series 2048F ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 16 1.5 million IPv4 routes and up to 256,000 IPv6 routes • CER 2000 Series 2048C -- accommodates 48-port 10/100/1000 Copper RJ45 model with 4 combination 100/1000 Hybrid Fiber (HF) ports ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 17 This device has the ability to simultaneously store up to 1.5 million IPv4 routes and up to 256,000 IPv6 routes FIGURE 9 CER 2000 Series 2024C-4X-RT FIGURE 10 CER 2000 Series 2024F-4X-RT FIGURE 11 CER 2000 Series 2024C ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 18 Introduction FIGURE 12 CER 2000 Series 2024F FIGURE 13 CER 2000 Series 2048C FIGURE 14 CER 2000 Series 2048F ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 19: Product Overview

    Backbone Bridge (PBB) functionalities in the same device. With these capabilities, the CER 2000 Series addresses a diverse set of needs in service provider networks and enterprise applications, as well as metro edge networks and small data centers. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 20: Software Features

    -RT features full MPLS capabilities as the original ExtremeRouting CER, and has the ability to simultaneously store up to 1.5 million IPv4 routes and up to 256,000 IPv6 routes. All ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series devices can be upgraded to premium packages. Upgrade applications You can convert (upgrade) your CES 2000 Series device.

  • Page 21: Hardware Features

    Hardware features Hardware features This section describes the physical characteristics of the ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series devices. For details about physical dimensions, power supply specifications, and pinouts, refer to the Hardware Specifications on page The following figures show the front panels of the various CES 2000 Series and CER Series 2024 and 2048 devices.

  • Page 22: Ces 2000 Series 2024C

    SFP ports, one DB9 serial management interface port labeled Console, one 10/100/1000 MbE RJ45 out-of-band management port, one resilient six-unit fan tray, and two AC power supply bays for 1+1 redundancy with one 500W AC power supply included. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 23: Ces 2000 Series 2048Cx

    Console, one 10/100/1000 MbE RJ45 out-of-band management port, one resilient six-unit fan tray, and two AC power supply bays for 1+1 redundancy with one 500W AC power supply included. FIGURE 25 CES 2000 Series 2048F device Forty eight 100/1000 MbE SFP ports ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 24: Ces 2000 Series 2048Fx

    FIGURE 27 CER 2000 Series 2024C device with the optional 2 ports of 10-G XFP uplink Optional 10 GbE XFP ports Four combination 100/1000 MbE SFP ports Twenty-four 10/100/1000 MbE RJ45 ports ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 25: Cer 2000 Series 2024F

    MbE RJ45 out-of-band management port, one resilient six-unit fan tray, and two AC power supply bays for 1+1 redundancy with one 500W AC power supply included. FIGURE 29 CER 2000 Series 2048C device Four combination 100/1000 MbE SFP ports Forty-eight 10/100/1000 MbE RJ45 ports ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 26: Cer 2000 Series 2048Cx

    AC power supply bays for 1+1 redundancy with one 500W AC power supply included. FIGURE 31 CER 2000 Series 2048F device Forty eight 100/1000 MbE SFP ports ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 27: Cer 2000 Series 2048Fx

    Console) is located in the front panel. Port LEDs The ports on the devices provide status information using the LEDs listed in Table 3 Table ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 28 The 10/100/1000 ports on the device use auto-sensing and auto-negotiating to determine the speed (10 Mbps, 100 Mbps, or 1000 Mbps) and duplex mode (full-duplex or half-duplex) of the port at the other end of the link and adjust port speed accordingly. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 29 100 Mbps or 1 Gbps. Into a physical port, you must insert a fiber-optic transceiver provided by Extreme Networks. The SFP-compliant fiber-optic modules provide an optical transceiver or physical medium-dependent (PMD) interface for fiber that can be used with the LAN physical layer...
  • Page 30 If a port’s region does affect configuration or operation of a feature, it is noted and described in the appropriate feature section of this guide. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 31: Network Interfaces

    EXTREME NETWORKS, Version: Part# : FTLX8511D3-F1 , Serial#: KCP02X8 Port 2/2: Type : 10GBASE-SR/SW (XFP) Vendor: EXTREME NETWORKS, Version: Part# : TRF2000EN-LF251 , Serial#: T07J23170 All show media done ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 32: Power Supplies

    AC power supply. FIGURE 33 AC Power Supply Power supply Six cooling fans DC power supplies The DC power supply is shown in the diagram DC power supplies. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 33: Cooling System And Fans

    FIGURE 35 Cooling Fans Six cooling fans The device cooling fans use pull configuration to move the air from the front to the back of the device. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 34 If a single fan fails within the assembly, the fan tray should be replaced. The fan tray is hot swappable and the mean time to recover (MTTR) is one minute. The system uses a default or configured temperature threshold associated with it to determine at which speed the fan should operate. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 35: Connecting To A Network Device

    Password assignment DANGER The procedures in this manual are for qualified service personnel. By default, the device’s CLI is not protected by passwords. To secure CLI access, Extreme Networks strongly recommends assigning passwords. The CLI contains the following access levels: •...

  • Page 36: Ip Address Configuration

    To enter a classical network mask, enter the mask in IP address format. For example, enter "209.157.22.99 255.255.255.0" for an IP address with a Class-C sub-net mask. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 37: Assigning An Ip Address To A Management Interface

    You can use Extreme Network Advisor to assign IP addresses to virtual routing interfaces only. By default, you can configure up to 24 IP interfaces on each interface, virtual interface, and loopback interface. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 38: Enabling And Disabling The Interfaces

    For security reasons, by default, the telnet server is disabled on the devices. To enable the telnet server and allow access through telnet to the device from an external host, execute the following.device(config)# telnet server ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 39: Management Port Function Overview

    For information on installing fiber-optic modules see Device connection. For information on cabling a fiber-optic module, see Device connection. For information on cleaning a fiber-optic module, see Device connection. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 40 ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 41: Installation

    A management station, such as a PC running a terminal emulation application. • A straight-through EIA/TIA DB-9 serial cable (F/F). The serial cable can be ordered separately from Extreme Networks. If you prefer to build your own cable, refer to the pinout information in General requirements.

  • Page 42: Summary Of Installation Tasks

    Batteries used for RTC/NVRAM backup are not located in operator-access areas. There is a risk of explosion if a battery is replace by an incorrect type. Dispose of used components with batteries according to local ordinance and regulations. DANGER All fiber-optic interfaces use Class 1 lasers. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 43: Lifting Precautions

    (The device can be running while a power supply is being installed or removed, but the power supply itself should not be connected to a power source.) ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 44: Installation Site Preparation

    Cabling infrastructure Ensure that the proper cabling is installed in the site. Refer to Cabling infrastructure or www.extremenetworks.com for a summary of supported cabling types and their specifications. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 45: Installation Location

    Redundant power supply installation The Extreme Networks device ships with one alternating-current (AC) power supply or direct-current (DC) power supply. All models have two power supply slots, enabling you to install a second power supply for redundancy. If desired, you can install a second supply for redundancy.
  • Page 46 Redundant power supply installation FIGURE 36 Use the following procedures for AC power supplies in the ExtremeSwitching CES 2000 Series, and ExtremeRouting CER 2000 Series devices. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 47 Secure the two screws near the edges of the supply to lock the supply in place. Lift the AC cord retainer clip. Connect the power cord to the power supply. Snap the AC cord retainer clip over the power cord. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 48: Installing A Dc Power Supply

    Connect the plug end of the power cord into outlet. CAUTION For an Extreme Networks AC system, use a ground wire of at least 6 American Wire Gauge (AWG). The ground wire should have an agency-approved crimped connector (provided with the chassis) attached to one end, with the other end attached to building ground.
  • Page 49 Never insert the power supply upside down. NOTE The power supply is right-side up when the manufacturer label is on the top. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 50 Secure the two screws near the edges of the supply to lock the supply in place (Installing a DC power supply). FIGURE 40 DC power supply screws Chassis attachment screws Assembly screws ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 51: Device Installation

    Installing the device in a rack For rack mount installation, Extreme Networks recommends that you use the rack mount ears attached to the unit. Each unit ships with rack ears attached to the front of the unit. You can mount the rack ears in 4 different locations on the device.
  • Page 52 Device installation FIGURE 41 Front rack mount position ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 53 Device installation 5 Inch offset rack mount position FIGURE 42 5 Inch offset rack mount position ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 54 Device installation Mid rack mount position FIGURE 43 Mid rack mount position ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 55 Device installation Reverse rack mount position FIGURE 44 Reverse rack mount position ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 56: System Power

    Four #10-24 screws (or as specified by rack type) to mount the device to the rack System power After you complete the physical installation of the system, you can power on the system. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 57: Powering On The System

    Connect the power cord supplied with the device to the power connector on the power supply on the rear of the device. Insert the other end into a properly grounded electrical outlet. Verify that the LED for each power supply is a solid green. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 58: Observing The Power Status Leds

    Left side of front panel Green The fan tray is powered on and is operating normal. Amber or green blinking The fan tray is not plugged in. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 59: Pc Or Terminal Attachment

    Connect a PC or terminal to the serial port of the system using a straight-through cable. The serial port has a male DB-9 connector. NOTE You need to run a terminal emulation program on the PC. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 60 The EIA/TIA 232 serial communication port serves as a connection point for management by a PC or SNMP workstation. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 61: Device Management Applications Familiarization

    CLI Functionality Once an IP address is assigned to the Extreme Networks device’s management port, you can access the CLI through a PC or terminal attached to the device’s serial (Console) port or 10BaseT/100BaseTX Ethernet (management) port, or from a Telnet or SSH connection to the PC or terminal.

  • Page 62: Command Completion

    Ctrl-D Deletes the character at the cursor. Ctrl-E Moves to the end of the current command line. Ctrl-F Moves the cursor forward one character. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 63: Searching And Filtering Output From Cli Commands

    The following command filters the output of the show who command so it displays only lines that do not contain the word "closed". This command can be used to display open connections to an Extreme Networks device. device# show who | exclude closed...
  • Page 64 The following command filters the output of the show who command so it displays output starting with the first line that contains the word "SSH". This command can be used to display information about SSH connections to the Extreme Networks device.
  • Page 65 The asterisk matches on zero or more sequential instances of a pattern. For example, the following regular expression matches output that contains the string "abc", followed by zero or more Xs: abcX* ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 66 "1002", "2100", and so on: _100_ Square brackets enclose a range of single-character patterns. For example, the following regular expression matches output that contains "1", "2", "3", "4", or "5": [1-5] ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 67 If you want to filter for a special character instead of using the special character as described in the table above, enter "\ " (backslash ) in front of the character. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 68 ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 69: Hardware Specifications

    Electromagnetic approvals.....................................72 • Port specifications......................................72 Power specifications This section contains the power specifications for the ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series devices. Table 13 provides the minimum and maximum voltage and current ratings. TABLE 13 Operating voltage and current...

  • Page 70: Physical Dimensions

    CES 2000 Series 2048FX 1 RU1.7 inches4.4 cm 17.44 in44.3 cm 17.25 in43.9 cm 17.5 CER 2000 Series 1 RU1.7 inches4.4 cm 17.44 in44.3 cm 17.64 in44.8 cm 20.9 2024C-4X-RT ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 71: Operating Environment

    The cooling fans cool the CPU, main memory, and voltage regulators. The fans use a pull configuration to move the air from the front of the device to the back of the device. • Total cooling capacity: 350 watts • Total air flow: 267 LFM ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 72: Safety Agency Approvals

    (Type 2 or Type 4 ports as described in GR-1089-CORE, Issue 5) and require isolation from the exposed OSP cabling. The addition of Primary Protectors is not sufficient protection in order to connect these interfaces metallically to OSP wiring. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 73: Console Port Pin Assignments

    Most PC serial ports require a cable with a female DB-9 connector. However, terminal connections will vary, requiring a cable with either a DB-9 or DB-25 connector, male or female. Serial cable options between the Extreme Networks device and a PC or terminal are shown in Figure...
  • Page 74 Port specifications TABLE 18 Management port pin assignments Pin number MDI-X ports Not used (10BaseT)CMT (100BaseTX) Not used (10BaseT)CMT (100BaseTX) Not used (10BaseT)CMT (100BaseTX) Not used (10BaseT)CMT (100BaseTX) ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 75: Hardware Maintenance

    CER 2000 Series 2024F models. Power supply replacement You can replace a power supply while the Extreme Networks device is powered on and running. The power supplies are located in slots at the rear of the device. This section provides information about the following topics: •...

  • Page 76: Determining Which Power Supply Failed

    If the display indicates "Installed (Failed)" for any of the slots, the power supply installed in that particular slot has failed. AC power supply The AC power supply is shown in the following diagram. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 77: Power Supplies For The Devices

    If you need to install a redundant power supply, it may be easier to install it before mounting the device, although the power supplies are "hot swappable" and can be installed or removed after the device is mounted and powered on. Extreme Networks recommends that you disconnect the power supply from AC power before installing or removing the supply.
  • Page 78 Unscrew the two power supply locking screws located at the top left and bottom right hand corner of the power supply. FIGURE 49 Power supply screw location Power supply locking screws ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 79 Remove the power supply or cover plate currently in the power supply bay you wish to install the power supply in. Refer to Removing the AC power supply on page 77 for details. Remove the new power supply from its packaging. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 80 The following procedures are required when removing an DC power supplies from devices. Remove the wires from your DC power source. Unscrew the two assembly screws to unlock the DC wiring assembly (Required tools) and remove the adapter. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 81 Pull the power supply outward once the screws have been unscrewed. This will disconnect the power supply from the backplane. Pull it completely free of the chassis. Place the power supply in an anti-static bag for storage. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 82 FIGURE 54 The DC power supply Insert the wires into the DC wiring assembly (Installing a DC power supply). Use the wire tightening screws to secure the wires. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 83 Carefully follow the mechanical guides on each side of the power supply slot and make sure the power supply is properly inserted in the guides. Never insert the power supply upside down. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 84 P/N LCD6-10A, and two 10-32, PPH, screws to secure crimp connector to chassis. Grounding position is located on the side of the chassis adjacent ground symbol. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 85: Verifying Proper Operation

    To verify the proper operation of the power supply after power on, you can observe the LEDs on the power supply. After the Extreme Networks device powers on, you can observe the LEDs on the front of the device to verify that it initialized successfully.

  • Page 86: 10-Gigabit Ethernet Module Installation Or Replacement

    The 2-port 10-Gigabit Ethernet modules may optionally be installed or replaced in the field on the CES 2000 Series 2024C, CES 2000 Series 2024F, CER 2000 Series 2024C, CER 2000 Series 2024F units. You can order the Extreme Networks device with a 2 x10-Gigabit module installed at the factory, or you can upgrade your device later.

  • Page 87: Installing A 2 X10-Gigabit Ethernet Module

    Replacing the fan tray The Extreme Networks device cooling fans use pull configuration to move the air from the front to the back of the device. The fans in the Extreme Networks device include six four-speed fans that operate at low speed, medium speed, medium-high speed, and high speed based on the ambient temperature and configured or default temperature thresholds.

  • Page 88: Copper Or Fiber Optic Module Replacement

    Plug the chassis back in and power up. Copper or Fiber optic module replacement You can remove an SFP, SFP+, or XFP from a port and replace it with a new one while the Extreme Networks device is powered on and running.

  • Page 89: Installing A New Copper Or Fiber Optic Module

    You must install a fiber optic module (SFP, SFP+, or XFP transceiver) in each Gigabit Ethernet and 10-Gigabit Ethernet fiber port you want to use. You can install a new fiber optic module in a port while the device is powered on and running. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 90: Cabling A Fiber Optic Module

    Tunable 10 GbE DWDM SFP+ NOTE Tunable 10 GbE DWDM SFP+ are only supported on ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series 4x10G models only. The tunable 10 GbE dense wavelength-division multiplexing (DWDM) SFP+ modular optic (part number 10G-SFPP-ZRD-T) can be configured through the CLI to use C-band channels 1 - 102 for flexible metro or campus Ethernet links that reach up to 80 km.

  • Page 91: Fiber Optic Connector Cleaning

    To clean the fiber cable connectors, Extreme Networks recommends using the fiber-optic reel-type cleaner that shipped with your device. You can also purchase this type of cleaner from the following web site.
  • Page 92 ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 93: Regulatory Statements

    This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations, ICES-003 Class A. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 94: China Cc Statement

    This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 95: Fcc Warning (Us Only)

    (VCCI). If this equipment is used in a domestic environment, radio disturbance might arise. When such trouble occurs, the user might be required to take corrective actions. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 96: Japan Power Cord

    EN 60950/IEC 60950 Safety of Information Technology Equipment Regulatory compliance (environmental) • 2014/35/EU and 2014/30/EU • 2011/65/EU - Restriction of the use of certain hazardous substance in electrical and electronic equipment (EU RoHS). ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 97 • SJ/T 11363-2006 Requirements for Concentration Limits for Certain Hazardous Substances in EIPs (China). • SJ/T 11364-2006 Marking for the Control of Pollution Caused by EIPs (China). ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 98 ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 99: Caution And Danger Notices

    Lassen Sie keine Werkzeuge im Chassis zurück. MISE EN GARDE Ne laissez jamais d'outils à l'intérieur du châssis PRECAUCIÓN No deje nunca herramientas en el interior del chasis. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 100: Electrical Cautions

    Assurez-vous que le dispositif ne risque pas de surcharger les circuits d'alimentation, le câblage et la protection de surintensité. Pour déterminer le risque de surcharge des circuits d'alimentation, additionnez l'intensité nominale (ampères) de ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 101 ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 102 20 amperios, mínimo de -48 VCC, bipolar, en la entrada al bloque terminal. El cableado de entrada para la conexión al producto deberá ser catalogado de cobre, 12 AWG, marcado VW-1, y nominal para 90 grados Celsius. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 103 CAUTION For an Extreme Networks AC system, use a ground wire of at least 6 American Wire Gauge (AWG). The ground wire should have an agency-approved crimped connector (provided with the chassis) attached to one end, with the other end attached to building ground.

  • Page 104: Cautions Related To Equipment Weight

    Les procédures décrites dans ce manuel doivent être effectuées par un personnel de maintenance qualifié. PELIGRO Los procedimientos de este manual deben llevarlos a cabo técnicos cualificados. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 105: Electrical Dangers

    Esta marca será su garantía de que el cordón de corriente puede ser utilizado con seguridad con el instrumento. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
  • Page 106 Verifique que elige el instrumento para circuitos apropiado dependiendo del número de suministros de energía de CC instalados en el chasis. La llamada de corriente mínima para el sistema es de un suministro de energía de CC. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 107: Dangers Related To Equipment Weight

    Monte los instrumentos que instale en un bastidor lo más bajos posible. Ponga el instrumento más pesado en la parte inferior y los instrumentos progresivamente más livianos más arriba. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...

  • Page 108: Laser Dangers

    Alle Glasfaser-Schnittstellen verwenden Laser der Klasse 1. DANGER Toutes les interfaces en fibre optique utilisent des lasers de classe 1. PELIGRO Todas las interfaces de fibra óptica utilizan láser de clase 1. ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide 9035631-01...
