Ces 2000 Series 2048Cx; Ces 2000 Series 2048F - Extreme Networks ExtremeSwitching CES 2000 Series Hardware Installation Manual

FIGURE 23 CES 2000 Series 2048C device
1
2

CES 2000 Series 2048CX

CES 2000 Series 2048CX (Copper) has forty-eight 10/100/1000 MbE RJ45 ports plus two 10 GbE XFP ports, one DB9 serial
management interface port labeled Console, one 10/100/1000 MbE RJ45 out-of-band management port, one resilient six-unit fan
tray, and two AC power supply bays for 1+1 redundancy with one 500W AC power supply included.
FIGURE 24 CES 2000 Series 2048CX device
1
2

CES 2000 Series 2048F

CES 2000 Series 2048F (Fiber) has forty-eight 100/1000 MbE SFP ports, one DB9 serial management interface port labeled
Console, one 10/100/1000 MbE RJ45 out-of-band management port, one resilient six-unit fan tray, and two AC power supply bays
for 1+1 redundancy with one 500W AC power supply included.
FIGURE 25 CES 2000 Series 2048F device
1
ExtremeSwitching CES 2000 Series and ExtremeRouting CER 2000 Series Hardware Installation Guide
9035631-01
Four combination 100/1000 MbE SFP ports
Forty-eight 10/100/1000 MbE RJ45 ports
10 GbE XFP ports
Forty-eight 10/100/1000 MbE RJ45 ports
Forty eight 100/1000 MbE SFP ports
Hardware features
