Hardware features
TABLE 5 SFP-compliant transceivers for the 100/1000 Ethernet interface module (continued)
Part number
E1MG-CWDM80-1530
E1MG-CWDM80-1550
E1MG-CWDM80-1570
E1MG-CWDM80-1590
E1MG-CWDM80-1610
E1MG-100FX
E1MG-100FX-IR
E1MG-100FX-LR
10 Gigabit Ethernet ports
A 10 Gigabit Ethernet module contains two or four physical ports, through which you can connect your device to other network devices
at a speed of 10 Gigabits.
Into a physical port, you must insert a fiber-optic transceiver provided by device. The XFP/SFP+-compliant fiber-optic modules provide
an optical transceiver or physical medium-dependent (PMD) interface for single or multi-mode fiber that can be used with the LAN
physical layer (PHY).
The following 10 Gigabit optics are available from device.
TABLE 6 MSA-compliant Optics for the 10 GbE Ethernet interface module
Part number
Devices with up to two 10GbE ports (XFP)
10G-XFP-SR
10G-XFP-LR
10G-XFP-ER
10G-XFP-ZR
10G-XFP-ZRD
10G-XFP-CX4
Devices with up to four 10GbE ports (SFP+)
10G-SFPlus-SR
10G-SFPlus-LR
10G-SFPlus-ZR
10G-SFPlus-ZRD
Port regions
Ports on the devices are grouped into regions. For a few features, such as port monitoring and unknown unicast configurations, you will
need to know the region to which a port belongs. However, for most features, a port's region does not affect configuration or operation of
the feature. If a port's region does affect configuration or operation of a feature, it is noted and described in the appropriate feature
section of this guide.
30
Description
CWDM SFP optic, 80Km, 1530nm, LC connector
CWDM SFP optic, 80Km, 1550nm, LC connector
CWDM SFP optic, 80Km, 1570nm, LC connector
CWDM SFP optic, 80Km, 1590nm, LC connector
CWDM SFP optic, 80Km, 1610nm, LC connector
100Base-FX SFP optic multi-mode fiber, LC connector
100BaseFX-IR optic for SMF with LC connector. For distances up to
15nm.
100BaseFX-LR SFP optic for SMF with LC connector. For distances up
to 40km.
Description
850nm serial pluggable XFP optic, target range 300m over multi-mode
fiber
1310nm serial pluggable XFP optic for up to 10km over single-mode
fiber
1550nm serial pluggable XFP optic for up to 40km over single-mode
fiber
1550nm serial pluggable XFP optic for up to 80km over single-mode
fiber
10GBase-ZR DWDM, XFP optic, 80km, 1530.33 to 1561.42
10-Base-CX4, XFP transceiver, 15km, CX connector
