- Page 1 Installing Ethernet Routing Switch 3600 Series 9036470-00 Rev AA February 2020...
- Page 2 2017-2020, Extreme Networks, Inc. All Rights Reserved. Legal Notice Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.
-
Page 3: Table Of Contents
Contents Chapter 1: About this Document..................... 5 .......................... 5 Purpose .......................... 5 Conventions ....................... 5 Text Conventions ..................... 7 Documentation and Training .......................... 8 Getting Help ......................... 9 Providing Feedback Chapter 2: New in this document.................. 10 Chapter 3: Preinstallation Checklist.................. 11 Chapter 4: Installation Preparation.................. 13 ........................ 13 Switch Models ............ - Page 4 Contents .......... 39 Assigning IP Parameters Using Enterprise Device Manager .............. 39 Verifying Assigned IP Address is Reachable Chapter 6: Installation Reference.................. 40 .................. 40 Console and Management Connections ........................ 40 Console Port ........................ 41 USB Port Chapter 7: Safety Messages.................... 42 Appendix A: Regulatory and Compliance Information............ 46 ..............
-
Page 5: Chapter 1: About This Document
Chapter 1: About this Document This section discusses the purpose of this document, the conventions used, ways to provide feedback, additional help, and information regarding other Extreme Networks publications. Purpose This document provides the information and procedures required to install the hardware, software, cabling, and power for the Ethernet Routing Switch 3600 Series. - Page 6 About this Document Icon Alerts you to... Helpful tips and notices for using the product. Tip: Situations that will result in severe bodily injury; up to Danger: and including death. Risk of severe personal injury or critical loss of data. Warning: Risk of personal injury, system damage, or loss of Caution:...
-
Page 7: Documentation And Training
Data Center products Other resources, like white papers, data sheets, and case studies Extreme Networks offers product training courses, both online and in person, as well as specialized certifications. For details, visit www.extremenetworks.com/education/. February 2020 Installing Ethernet Routing Switch 3600 Series... -
Page 8: Getting Help
579 2826. For the support phone number in your country, visit: www.extremenetworks.com/support/contact Before contacting Extreme Networks for technical support, have the following information ready: • Your Extreme Networks service contract number, or serial numbers for all involved Extreme Networks products • A description of the failure •... -
Page 9: Providing Feedback
Providing Feedback Providing Feedback The Information Development team at Extreme Networks has made every effort to ensure the accuracy and completeness of this document. We are always striving to improve our documentation and help you work better, so we want to hear from you. We welcome all feedback, but we especially want to know about: •... -
Page 10: Chapter 2: New In This Document
Chapter 2: New in this document There are no changes to this document in this release. February 2020 Installing Ethernet Routing Switch 3600 Series... -
Page 11: Chapter 3: Preinstallation Checklist
20 for package. a description of the components that are provided with the switch. If any components are missing, contact Extreme Networks support. Make sure that the power cord has AC power cord specifications the correct country-specific page 18. - Page 12 Preinstallation Checklist Task Description path must be permanent and must not exceed 1 Ohm of resistance from the rack to the grounding electrode. Installing ERS 3600 in an equipment rack on page 25. February 2020 Installing Ethernet Routing Switch 3600 Series...
-
Page 13: Chapter 4: Installation Preparation
Chapter 4: Installation Preparation Switch Models The following table describes the ERS 3600 Series models. All switch models support autopolarity. Model Key features Part number ERS 3626GTS • 24 10/100/1000 ports AL3600?05-E6 • Two shared SFP ports • Two 1/10 Gigabit SFP+ ports operating in dual mode as uplink ports •... -
Page 14: Universal Serial Bus Ports On The Ers 3600 Series
Installation Preparation Model Key features Part number ERS 3650GTS-PWR+ • 48 10/100/1000 802.3at PoE ports and 2 AL3600A16-E6 shared SFP ports • Two 1/10 Gigabit SFP+ ports operating in dual mode as uplink ports • Two 10 Gigabit SFP+ ports as either uplink or stacking ports •... -
Page 15: Technical Specifications
Technical Specifications To protect the switch against ESD damage, take the following preventive measures before connecting any data cables to the device: • Always use antistatic wrist straps. Make sure the strap is adjusted to provide good skin contact. • Ensure that work surfaces and equipment racks are properly grounded for protection against electrostatic discharge. - Page 16 Installation Preparation Switch Specification Width ERS 3650GTS-PWR+, ERS 442 mm 3650GTS-PWR+, ERS 3626GTS, ERS 3626GTS-PWR+ Depth ERS 3650GTS, ERS 3626GTS, 280 mm ERS 3626GTS-PWR+ ERS 3650GTS-PWR+ 380 mm Weight ERS 3650GTS 3.93 kg ERS 3650GTS-PWR+ 6.25 kg ERS 3626GTS 3.57 kg ERS 3626GTS-PWR+ 4.75 kg Table 4: Electrical specifications...
-
Page 17: Power Specifications
Technical Specifications Environmental component Specification ERS 3626GTS - 41.2dB@25C, 49.3dB@50C ERS 3626GTS-PWR+ - 44.6dB@25C, 54.5dB@50C Miscellaneous Operating Considerations • At least 5cm (2") on each side of the switch unit for ventilation • Adequate power source within six feet. One 15 amp circuit required for each power supply •... -
Page 18: Ac Power Cord Specifications
Installation Preparation Table 7: Typical power consumption Model Idle Power Typical Power consumption (Watts) consumption Devices Devices With Energy Saver (Watts) connected to all connected to all enabled (PoE ports, typical ports, typical Saver disabled on traffic, without traffic, 6 W PoE models) SFPs average per PoE... -
Page 19: Supported Power Cords
AC Power Cord Specifications Table 9: International power cord specifications Country and plug description Specifications Typical plug Continental Europe 220 or 230 VAC • CEE7 standard VII male plug 50 Hz • Harmonized cord (HAR marking Single phase on the outside of the cord jacket to comply with the CENELEC Harmonized Document HD-21) U.S./Canada/Japan... -
Page 20: Verify The Package Contents
Installation Preparation Order Code Description Region AA0020063E6 POWER CORD 2.5M IEC C13 TO BS1363 United Kingdom AA0020064E6 POWER CORD 2.5M IEC C13 TO CEE 7/7 European Union AA0020065E6 POWER CORD 2.5M IEC C13 TO CEI 23-16 Italy AA0020066E6 POWER CORD 2.5M IEC C13 TO GB 2099.1-1996 China AA0020067E6 POWER CORD 2.5M IEC C13 TO BS-546/SANS164-1 India and South Africa... -
Page 21: Connecting Ac Power
Connecting AC Power Connecting AC Power Before you begin • To connect AC power to the switch an appropriate AC power cord is required. Ensure the switch power supply supports AC power input. Danger: Use only power cords with a grounding path. Without a proper ground, a person who touches the switch is in danger of receiving an electrical shock. - Page 22 Installation Preparation Procedure 1. Plug the female end of the AC power cord into the back of the switch power supply. Important: The switch powers on immediately when it is connected to a suitable AC power source. The switch does not have a power switch. 2.
-
Page 23: Chapter 5: Installing The Switch
Chapter 5: Installing the Switch Installing an ERS 3626GTS-PWR+ on a Table or Shelf You can install the switch model ERS 3626GTS-PWR+ on a flat surface such as a table or shelf. The surface must be able to support the combined weight of the switch and attached cables. An ERS 3626GTS-PWR+ weights 4.75kg (10.47lb). - Page 24 Installing the Switch 2. Set the switch on a table or shelf. February 2020 Installing Ethernet Routing Switch 3600 Series...
-
Page 25: Installing Ers 3600 In An Equipment Rack
Installing ERS 3600 in an Equipment Rack Installing ERS 3600 in an Equipment Rack Before you begin Tool requirements • Phillips screwdriver to attach brackets to the switch and the switch to the rack Rack requirements • Space of 2.8 inches (7.1 cm) for each 3626 or 3650 model is available in an E1A or 1EC standard 19 inch (48.2 cm) equipment rack and T1A 23 inch (58.5 cm) equipment rack. -
Page 26: Single And Multiple Switch Arrangements
Installing the Switch 3. Slide the switch into the rack. Insert and tighten the rack-mount screws. 4. Verify that the switch is securely fastened to the rack. Single and Multiple Switch Arrangements You can connect up to eight switch devices that are in one Rack Unit (RU) height in a stack to provide uninterrupted connectivity for up to 224 ports for ERS 3626GTS and ERS 3626GTS-PWR+ and up to 416 ports for ERS 3650GTS and ERS 3650GTS-PWR+. -
Page 27: Stack Arrangement
Standalone Arrangement Stack Arrangement You connect the switches in the stack by the stack connectors. You designate one unit as the base unit by setting a switch on the back panel. The stack connector is a component of the back panel and consists of the Base Unit Select switch, Cascade Down connector, and Cascade Up connector. -
Page 28: Cascade Down
Installing the Switch individual units maintain their original unit numbering, even if the position of one or more units in the stack is changed. For example, when the stack is initially powered, the base unit becomes unit 1 and the unit that the base unit connects to (through the Cascade Down cable) becomes unit 2 (and the next unit is unit 3 and so on), until the maximum stack configuration (up to eight units) is reached. -
Page 29: Cascade Up
Standalone Arrangement Figure 3: Cascade down configuration Note: Return cable length might vary depending on unit spacing. Ensure you order the proper length return cable to provide adequate strain relief. Important: Because many network management software packages assume a cascade down (stack down) configuration, we recommend the usage of this configuration. -
Page 30: Redundant Cascade Stacking
Installing the Switch Cascade Up connector physically located at the bottom of the stack. This next unit is designated Unit 2. The stack is wired upward through the units and the system continues to number in this manner throughout the stack. In this configuration, the base unit discovers the stack in a cascade up (stack up) direction. -
Page 31: Stack Configuration
Identifying Cables to use with the Switch Stack Configuration You can change base unit switches with switches on (hot), but changes do not take affect until switches are rebooted. Selecting a Base Unit Procedure 1. Determine which unit will be the base unit. 2. -
Page 32: Connecting A Transceiver To The Switch Or Stack
10/100 ports, they are configured as an MDI-X connection. Connecting a Transceiver to the Switch or Stack The following sections describe small form factor pluggable (SFP) transceivers. For more information about transceiver use and designation, see Extreme Networks Pluggable Transceivers Installation Guide. Installing Transceivers Procedure 1. -
Page 33: Supported Optical Devices
Important: We recommend that you use SFP and SFP+ transceivers as they undergo extensive qualification and testing. Extreme Networks will not be responsible for issues related to third party transceivers. Small Form-Factor Pluggable (SFP) Transceivers SFPs are hot-swappable input and output enhancement components designed to allow gigabit Ethernet ports to link with other gigabit Ethernet ports over various media types. -
Page 34: Checking Status Leds To Verify Switch Installation
Model Description Part number Important: The following SFP transceivers with the part numbers:AA1419013–E5, AA1419014–E5, AA1419015– E5, and AA1419025–E5 to AA1419040–E5. However, Extreme Networks recommends using the newer DDI versions of these SFP transceivers. 1000BASE-T SFP Gigabit Ethernet, RJ–45connector AA1419043–E6 1000BASE-SX DDI SFP 850 nm, GigabitEthernet, duplex AA1419048–E6... - Page 35 Checking Status LEDs to Verify Switch Installation Note: When used as Stacking ports, the LEDs on the left of the switch indicate Stack port status. The Stack Up and Stack Down LEDs are updated as the Stack ports become active or idle. Their local port LEDs do not indicate Stack port status.
- Page 36 Installing the Switch State Description The unit power is off. Green (Solid) Normal operation. Status System cannot work properly (like temperature is too high). Amber (Solid) The system failed self-test. Green (Solid) Normal operation. UP/Down No Stack-up or Stack-down connection is detected. Amber (Solid) A Stack-up or Stack-down cable is detected, but...
-
Page 37: Ip Address Information Configuration
IP Address Information Configuration Table 12: SFP+ transceiver Port LED state indicators Label Color/Status Description No link established. Solid Green SFP+ detected and link established. Green / blinking SFP+ link established and transmit activity detected. Solid Amber SFP detected and Link established. -
Page 38: Accessing The Console Menu
3. Connect to the switch using the terminal or terminal emulation application. 4. After the Extreme Networks banner is displayed, press CTRL + Y to display the main menu. The version of the main menu displayed is dependent on whether the switch is part of a standalone or stacked switch configuration. -
Page 39: Assigning Ip Parameters Using Enterprise Device Manager
IP Address Information Configuration Table 13: Terminal emulation settings Property Value Baud Rate 9600 bps Data Bits Stop Bits Parity None Flow Control None Assigning IP Parameters Using Enterprise Device Manager Procedure 1. Connect a computer to the switch through a data port using a standard RJ-45 network cable. 2. -
Page 40: Chapter 6: Installation Reference
Chapter 6: Installation Reference Console and Management Connections The front panel of the switch contains the Status LEDs, Console port, and a USB 2.1 port. The rear panel of the switch contains the Base Unit switch. Console Port The console port is the RJ45 port with a blue border outline. You can use the console port to establish a management terminal connection to the switch. -
Page 41: Usb Port
Console and Management Connections RJ45 console port pin-out Signal Requirement RXD (receive data) Mandatory DSR (data set ready) Optional CTS (clear to send) Optional (can be swapped or linked with pin USB Port The USB port is a Standard Type-A female USB 2.1 port. The switch provides USB host functionality and can support USB flash drives. -
Page 42: Chapter 7: Safety Messages
Chapter 7: Safety Messages Caution: When mounting this device in a rack, do not stack units directly on top of one another in the rack. Each unit must be secured to the rack with appropriate mounting brackets. Mounting brackets are not designed to support multiple units. Important: Achtung: Wenn diese Einheit in einem Rack montiert wird, muß... - Page 43 Caution: If you are not installing a module in the slot, be sure to keep the metal cover plate in place over the slot. Removing the cover plate impedes airflow and proper cooling of the unit. Important: Achtung: Wenn Sie kein Modul im Schacht verwenden, muß die Metallabdeckung über dem Schacht montiert sein.
- Page 44 Safety Messages Warning: Disconnecting the AC power cord is the only way to turn off AC power to this device. Always connect the AC power cord in a location that can be reached quickly and safely in case of an emergency.
- Page 45 Important: Peligro: Utilice únicamente cables de alimentación con toma de tierra. De lo contrario, al tocar el interruptor puede recibir una descarga eléctrica. Si no hay un circuito de toma de tierra en el enchufe, puede producirse un exceso de emisiones. Important: Pericolo: Utilizzare esclusivamente cavi di alimentazione dotati di un percorso per la messa a terra.
-
Page 46: Appendix A: Regulatory And Compliance Information
Appendix A: Regulatory and Compliance Information Federal Communications Commission (FCC) Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 47: Class A Ite Notice
Class A ITE Notice Class A ITE Notice Warning: This equipment is compliant with Class A of CISPR 32. In a residential environment, this equipment may cause radio interference. Klasse A ITE Anmerkung WARNHINWEIS: Dieses Produkt zählt zur Klasse A ( Industriebereich ). In Wohnbereichen kann es hierdurch zu Funkstörungen kommen, daher sollten angemessene Vorkehrungen zum Schutz getroffen werden. -
Page 48: Electromagnetic Compatibility (Emc)
Regulatory and Compliance Information Electromagnetic Compatibility (EMC) This product complies with the following: FCC 47 CFR Part 15 (Class A), ICES-003 (Class A), EN 55032 (Class A), EN 55024, EN 61000-3-2, EN 61000-3-3, AS/NZS CISPR 32 (Class A), VCCI V-3, 2004/108/EC (EMC Directive) Elektro-magnetische Kompatibilität (EMC) Dieses Produkt entspricht den folgenden Richtlinien: FCC 47 CFR Part 15 (Class A), ICES-003... -
Page 49: Ccc Emc Statement - China
CCC EMC Statement — China CCC EMC Statement — China This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Battery Warning — Taiwan Battery Notice Warning: This product contains a battery used to maintain product information. -
Page 50: Restriction Of Hazardous Substances
4. It is the users’ responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please contact Extreme Networks Customer Support at +353 61 705500 (Ireland). February 2020 Installing Ethernet Routing Switch 3600 Series... -
Page 51: Safety
Safety Safety Compliant with IEC 60950-1:2005 (Second Edition); Am1:2009 + Am2:2013, EN 60950-1:2006 + A1:2010 + A11:2009 + A12:2011 + A2:2013, UL 62950-1, 2nd Ed. 2011, CSA C22.2 No. 60950-1-07, 2nd Ed. 2011 February 2020 Installing Ethernet Routing Switch 3600 Series...
