Mechanical Installation
3 3
Illustration 3.8 Approved Procedure for Fork Lift Transport of a
Double Enclosure

3.6 Assembling a Standard Unit with a Pedestal

In most applications, the pedestal is used to allow airflow
into the unit cabinets to provide proper cooling.
CAUTION
The pedestal/plinth can be installed already, or delivered
as lose component, depending on the customer request
or transport limitations. The pedestal/plinth can be
required to allow air flow for proper cooling and/or cable
termination for maximum bending space.

3.6.1 Positioning the Pedestal

NOTICE
Prepare the mechanical installation of the VLT
Panel carefully to ensure a proper result and avoid extra
work during installation. To become familiar with the
space demands, start taking a close look at the
mechanical drawings in this manual and in the customer
documentation, delivered with the VLT
latest information.
18
®
VLT Plus Panel
max. 700 kg
(1543 lbs.)
Illustration 3.9 Approved Procedure for Fork Lift Transport of a
max. 700 kg
Triple Enclosure
(1543 lbs.)

3.5.4 Storage

Store the unit in a dry location. Keep the equipment
sealed in its packaging until installation.
Periodic forming (capacitor charging) is not necessary
during storage.
®
Plus
®
Plus Panel for
Danfoss A/S © 09/2015 All rights reserved.
max. 700 kg
(1543 lbs.)
1. Place the pedestal in desired location, paying
attention to the following:
•
Ambient conditions (see
chapter 5.1 Technical Design Consider-
ations)
•
Cooling requirements (see
chapter 3.2 Cooling)
•
Unit dimensions and door clearances
(see chapter 5.2 Dimensions)
2. Pull the cables (mains, 230 V supply, and motor
cables) up through the pedestal.
3. Bolt the pedestal to the floor.
max. 700 kg
(1543 lbs.)
max. 1400 kg
(3086 lbs.)
