Introduction
1
1
2
3
4
5
6
7
1
Air outlet, top
2
Air inlet, control
3
Local control panel
4
Door handle
5
Mains switch
6
Air outlet, electronic equipment/control
7
Plinth with air inlet, front (optional)
Illustration 1.2 VLT
6
VLT
1
®
Plus Panel, 250 kW Enclosure
Danfoss A/S © 09/2015 All rights reserved.
®
Plus Panel
2
3
4
5
6
7
1
Air outlet, top
2
Air inlet, control
3
Local control panel
4
Door handle
5
Mains switch
6
Air outlet, electronic equipment/control
7
Plinth with air inlet, front (optional)
Illustration 1.3 VLT
1
®
Plus Panel, 315 kW and 400 kW Enclosure
MG13B102
