Predator-Dualview Installation Manual V2.1.21.1

2 Housing Dimensional Drawing

A
B
C
D
Predator DUALVIEW
A3
1
253
MATERIAL:
THIS DRAWING AND ALL COPIES ARE
C COPYRIGHT PROTECTED AND
360 Vision Technology Ltd.
MUST NOT BE REPRODUCED OR SHOWN TO
Unit 7, Seymour Court,
ANY THIRD PARTY WITHOUT THE DIRECT WRITTEN
Manor Park, Runcorn, Cheshire,
PERMISSION OF THE AUTHOR.
WA7 1SY. United Kingdom.
www.360visiontechnology.com
1
2
585
PAN SWEEP
435
TILT
SWEEP
MOUNTING
BASE
125
MOUNTING BASE
- FINISH:
TOLERANCES:-
DO NOT SCALE
X = 0.5
ALL DIMENSIONS IN MM
X.X = 0.1
REMOVE ALL SHARP EDGES
3rd ANGLE PROJECTION
X.XX = 0.05
2
3
SCALE 0.3
10 (x4) ON
101.6 (4 INCH) PCD
Weight 10.5kg
- NAME: DATE : DESCRIPTION
ENGINEER: K.CRAIK 210317
PREDATOR ASSEMBLY -TC35 THERMAL
APPROVED:
RELEASED:
3
Page 4
4
SCALE 0.3
A 210317 FIRST ISSUE
ISS DATE REFERENCE
SCALE: SHEET:
0.300 1 OF 2
WITH LAMP - ALUMINIUM
PART NUMBER:
M5722-A
4
A3
A
B
C
D
