BATTERY CHARGE
Battery chargers
D Using the BC-240 to rapid charge
the BP-298/BP-299
The BC-240 provides rapid charging of only the
BP-298/BC-299 Li-ion battery pack. Never use it to
charge any other battery pack.

Charging time*

with the BP-298: Approximately 3 hours
with the BP-299: Approximately 4.6 hours
* When the Extend Battery Life function is turned OFF.
See the BASIC MANUAL for details.
The following item is additionally required:
A power adapter (not supplied with some transceiver
versions) or the OPC-515L or CP-23L DC power cable.
CAUTION: When using the OPC-515L DC power
cable NEVER connect the OPC-515L to a power
source using reverse polarity. This will ruin the
battery charger. White line: Black line:
+ –
Power adapter
(A different type, or no power
adapter is supplied, depending
on the transceiver version.)
The optional OPC-515L
(for a DC power source)
or CP-23L (for a 12 V
cigarette lighter socket)
can be used instead of
the power adapter.
2-3
Battery pack
Battery pack + Transceiver
Screws*
(Self tapping screw:
M3.5 × at least 30 mm)
* User supplied
Using screws are
recommended to
secure the charger.
Charging indicator
• Lights orange: While charging
• Lights green: When charging is completed.
• Blinks red: When a charging error has
occurred.
Turn OFF
