Using The Bc-191 To Rapid Charge The Bp-264 - Icom IC-V86 Advanced Manual

2
BATTERY CHARGE
Battery chargers
D Using the BC-191 to rapid charge
the BP-264
The BC-191 provides rapid charging of only the
BP-264 Ni-MH battery pack. Never use it to charge
any other battery pack.
Charging time: Approximately 2 hours
The following item is additionally required:
A power adapter (not supplied with some transceiver
versions) or the OPC-515L or CP-23L DC power cable.
D Using the BC-192 to regular charge
the BP-264
The BC-192 provides regular charging of only the
BP-264 Ni-MH battery pack. Never use it to charge
any other battery pack.
Charging time: Approximately 16 hours
The following item is additionally required:
A power adapter (not supplied with some transceiver
versions) or the OPC-515L DC power cable.
Power adapter
(A different type, or no power
adapter is supplied, depending
on the transceiver version.)
The optional OPC-
515L (for a DC power
source) or CP-23L
(for a 12 V cigarette
lighter socket) can be
used instead of the
power adapter.
Power adapter
(A different type, or no power
adapter is supplied, depending
on the transceiver version.)
The optional OPC-515L
(for a DC power source)
can be used instead of
the power adapter.
Charging time period differs,
depending on the input voltage.
12 V: Approximately 36 hours
13.8 V: Approximately 21 hours
16 V: Approximately 16 hours
2-2
Battery pack
Battery pack + Transceiver
Screws*
(Self tapping screw:
M3.5 × at least 30 mm)
* User supplied
Using screws are
recommended to
secure the charger.
Charging indicator
• Lights orange: While charging
• Lights green: When charging is completed.
Battery pack
Battery pack + Transceiver
Screws*
(Self tapping screw:
M3.5 × at least 30 mm)
* User supplied
Using screws are
recommended to
secure the charger.
Charging indicator
• Lights green while charging.
NOTE:
The charge indicator will not go
out even after a battery pack is
fully charged.
Turn OFF
Turn OFF
