Clu0Cf: Configurable Logic Unit 0 Configuration - Silicon Laboratories EFM8 Series Reference Manual

14.4.7 CLU0CF: Configurable Logic Unit 0 Configuration

Bit 7
Name OUTSEL
Access RW
Reset 0
SFR Page = 0x20; SFR Address: 0xB1
Bit Name
7 OUTSEL
Value
0
1
6 OEN
This bit enables the asynchronous output of CLU0 to CLU0OUT.
Value
0
1
5:4 Reserved
3 RST
Writing this bit to 1 resets the D flip flop for CLU0. The bit will immediately return to 0.
Value
1
2 CLKINV
Value
0
1
1:0 CLKSEL
Value
0x0
0x1
0x2
0x3
