16.4.10 PCA0CPL0: PCA Channel 0 Capture Module Low Byte

Bit 7
Name
Access
Reset
SFR Page = 0x0, 0x10; SFR Address: 0xFB
Bit Name
7:0 PCA0CPL0
The PCA0CPL0 register holds the low byte (LSB) of the 16-bit capture module. This register address also allows access to
the low byte of the corresponding PCA channel's auto-reload value for 9 to 11-bit PWM mode. The ARSEL bit in register
PCA0PWM controls which register is accessed.
A write to this register will clear the module's ECOM bit to a 0.

16.4.11 PCA0CPH0: PCA Channel 0 Capture Module High Byte

Bit 7
Name
Access
Reset
SFR Page = 0x0, 0x10; SFR Address: 0xFC
Bit Name
7:0 PCA0CPH0
The PCA0CPH0 register holds the high byte (MSB) of the 16-bit capture module. This register address also allows access
to the high byte of the corresponding PCA channel's auto-reload value for 9 to 11-bit PWM mode. The ARSEL bit in register
PCA0PWM controls which register is accessed.
A write to this register will set the module's ECOM bit to a 1.
