Working with a film magazine

You can optionally order the film magazine and the adapter from Sinar:
711.64.088
711.64.010
In the following, you will find the instructions for the attachment of the film magazine
and for inserting the film. For further details about working with the film magazine, refer
to the user manual of the manufacturer of the film magazine.
Remove the cover
Fig. 16 / 1 Remove protective cover
Attach the magazine frame
Fig. 16 / 2 Attach magazine frame
M
AGAZINE
Adapter frame
Film magazine
Firstly, remove the protective cover from the
camera body. Push the back release button
upwards.
Place the magazine frame into the four
openings. You will hear a click when the
magazine is locked. If using a 4,5 x 6 cm
magazine, the format symbol has to be
visible.
