Sinar Medium Format Camera System Hy6 Operating Manual page 8

C
ONTENTS
5 ASSEMBLY INSTRUCTIONS FOR THE CAMERA .............................................15
5.1 Viewfinder ................................................................................................15
5.1.1 Attachment and Removal of the Waist-level Viewfinder ............................... 15
5.1.2 Opening and Closing the Waist-level Viewfinder .......................................... 16
5.1.3 Opening and Closing the Magnifying Glass .................................................. 17
5.1.4 Replacing the Magnifying Glass.................................................................... 17
5.1.5 Use of the 90° Reflex Viewfinder.................................................................. 18
5.2 Attachment and Removal of the Lens .......................................................19
5.3 Attachment and Removal of the Sinarback ...............................................20
5.3.1 Attachment and Removal of the Protective Cover ........................................ 20
5.3.2 Assembly and Attachment of the Sinarback and the Adapter Plate .............. 21
5.3.2.1 Assembly and Attachment of a Sinarback eMotion ............................... 21
5.3.2.2 Attachment and Removal of a Sinarback 54 MC....................................... 23
5.4 Adjusting the hand grip ............................................................................25
5.5 Connecting the camera to a computer ......................................................25
5.6 Attaching a flash device............................................................................26
5.7 Replacing the focusing screen...................................................................26
5.8 Inserting and replacing the format mask ..................................................28
5.9 Adjusting the Shoulder Strap and the Hand Strap.....................................29
5.9.1 Attaching and Removing the Shoulder Strap ................................................ 29
5.9.2 Adjusting the Hand Strap ............................................................................ 30
6 BATTERY ......................................................................................................32
6.1 Inserting and removing the battery...........................................................32
6.2 Charging the battery .................................................................................33
7 FIRST USE OF THE SINAR HY6 SYSTEM ........................................................34
VII
