62 VAV Controller—Variable Air Volume Controller
VAV111-1
ANALOG INPUTS
DPT1
OUT 1
COM 2
VDC 3
Figure 30: Single Duct Fan Powered Box Wiring Example 4
Table 25: Fan Powered Box Wiring Example 4 Bill of Materials
Component Description
C1
VAV w/6 BOs and 2 AOs
Temperature Sensor
TE1
DPT-1/DA-1
Delta P Transducer/Damper
Actuator
VA-1
Valve Actuator Box Heat
VA-2
Electro-pneumatic Transducer
Baseboard Heat
Note: Box OEM manufacturers typically supply fan relays and electric
heat relays.
TE1
Zone
Sensor
BINARY IN
DSI
Box Damper
Actuator
BIN ARY OUTPUTS
VA1
DA1
Incremental
Box Heat
Actuator
VA2
Fan
Proportional
Relay
Valve Actuato
Baseboard
vavwe6a
Part Number
AS-VAV111-1
TE-6400 Series
ATP-2040
VA-8020-1
EP-8000-2
