Defining a VAV
1 5 F 1 6 F 1 7 F
Control Device
Object in
Metasys
Software
Note: You can load and commission the controller either locally with the
AS-CBLPRO-2 interface at the zone sensor (Figure 15) or from a
central location where the N2 has been pulled, controller's field
hardware addressed, and an MM-CVT101-1 interfaced to the laptop.
Using a Metasys Network system, you need to define a VAV Controller
device object by entering data into the Attribute menu as seen on the
Operator Workstation.
1. Go to the Network Map.
2. Double-click the system name in which you want to add the new VAV
object.
3. Click New in the Item pull-down menu.
4. Click on Type: N2 devices in the Item New dialog box.
Type
Accumulator
Analog data
Analog input
Analog output digital
Analog output setpoint
Binary data
Binary input
Binary output
MS data
MS input
Hardware system name:
Hardware object name:
Copy of (System\Object):
Figure 3: Item New Dialog Box
Note: The Hardware System and Hardware Object text fields are not
used for this object type.
5. Click OK to display the Add N2 Device dialog box.
VAV - Item New
MS output
Control system
DL/LR group
LC group
PID loop
Fire Zone
L2 devices
N2 devices
S2 devices
Card Reader
VAV Controller—Variable Air Volume (VAV) Controller 13
