The following table illustrates the selections made through HVAC PRO for
Windows for this example.
Note: The examples contained in this technical bulletin do not reflect all
of the possible questions and answers. These examples are
provided as a basic overview of wiring locations you might expect
to see.
Table 24: Example 4--Pressure Independent with Parallel Fan
HVAC PRO for Windows Questions
Control Strategy
Fan Type
Exhaust Box Required
Baseboard Heat Type
Box Heat Type
Lighting Integration
Plenum
Supply
DPT1
Figure 29: Mechanical System Flow Example 4
Pressure Independent w/Parallel Fan
Configuration Selections
Pressure Independent
Parallel Fan Temp Controlled
No
Analog Output
Incremental
No
R
DA1 VA1
C 1
VAV Controller—Variable Air Volume (VAV) Controller 61
H
Discharge
T
G
B
A
S
VA2
E
B
TE1
D
