54 VAV Controller—Variable Air Volume Controller
Point Point HVAC PRO for Windows
Type Name Configuration
(Cont.) Assignments and Defaults
BO 1 Supply Damper Open
Binary
BO 2 Supply Damper Close
Outputs
BO 3 Parallel and Series On-Off Fans None
Exhaust Box Open
Unused
BO 4 Exhaust Box Close
Baseboard Heat On-Off
First Stage Box Heat***
Unused
BO 5 Baseboard Incremental Open
Box Heat Incremental Open
First Stage Box Heat**
Second Stage Box Heat***
Lights On for VAV101
Unused
BO 6 Baseboard Incremental Close
Box Heat Incremental Close
On-Off/Single Stage Box Heat
Second Stage Box Heat**
Third Stage Box Heat***
Lights Off for VAV101
Unused
BO 7 Baseboard Incremental Open
on VAV100
Lights On for VAV100
Unused
BO 8 Baseboard Incremental Close
on VAV100
Lights Off for VAV100
Unused
Analog AO 1 S66 Output for
Proportional Series Fan
Outputs
Unused
AO 2 Proportional Box Heat
Unused
** 2-Stages Box Heat
*** 3-Stages Box Heat
HVAC PRO for Windows
Configuration Options
None
None
Unused
Rename
None
None
None
Rename
None
None
None
None
None
Rename
None
None
None
None
None
None
Rename
None
None
Rename
None
None
Rename
None
Rename
None
Rename
