Johnson Controls METASYS VAV110 Technical Manual page 58

58 VAV Controller—Variable Air Volume Controller
120/24VAC
120VAC
Power
Transformer
ANALOG INPUTS
DPT1
OUT 1
COM 2
VDC 3
DPT2
OUT 1
COM 2
VDC 3
Figure 26: Single Duct Wiring Example 2
Table 21: Single Duct Wiring Example 2 Bill of Materials
Component Description
C1 Digital Controller
TE1 Metastat
DA1 and DPT1 Actuator/ΔP Sensor
Valve Actuator
VA1
Actuator/DP Sensor
DA2 and DPT2
TE1
24VAC
Room
Sensor
BINARY IN
DSI
BIN ARY OUTPUTS
DA1
Damper
Actuator
VA1
DA2
Proportional
EXH
Valve
Actuator
vavwe2a
Part Number
AS-VAV111-1
TE-6400 Series
ATP-2040
VA-8022 Series
ATP-2040
