60 VAV Controller—Variable Air Volume Controller
120/24VAC
120VAC
Power
Transformer
C1
ANALOG INPUTS
Figure 28: Single Duct Wiring Example 3
Table 23: Single Duct Wiring Example 3 Bill of Materials
Component Description
Digital Controller
C1
TE1 Metastat
VA1 Baseboard Valve Actuator
Box Heat Valve Actuator
VA2
DA1 Damper Actuator
R1 Lighting Relay
TE1
24VAC
Zone
Sensor
BINARY IN
DSI
DA1
Damper
Actuator
BINARY OUTPUTS
VA1 VA2
Basbd Box
Heat Heat
Part Number
AS-VAV110-1
TE-6400 Series
J Series
VA-8020
EDA-2040-nn
GE-RR7
R1
Lighting
Relay
ON
COM C
OFF
vavwe3a
