1. Select VAV Applications.
1. Fill in job information.
- Option - Job Information
1. File - Save As
2. Select device type.
1. Attach MM-CVT101-1 Converter
or AS-CBLPRO-2.
2. Select Download - Current Configuration.
1. Attach MM-CVT101-1 Converter
or AS-CBLPRO-2.
2. Select Commission - Current Configuration.
3. Select Bus type, comm. port, and
N2 address (if N2 Bus).
4. Select OK.
5. View / Adjust parameter values.
12 VAV Controller—Variable Air Volume Controller
Start HVAC PRO for Windows
Complete Q/A Session
Complete Configuration Process
Save Configuration
Download Controller
Commission Controller
Exit HVAC PRO for Windows
Figure 2: Steps in Configuring a VAV Controller Using
HVAC PRO for Windows
Select File-New
2. Select Single or Dual Duct.
2. Review and change inputs/outputs.
3. Review and change default parameters.
3. Enter file name for configuration file.
3. Select Bus type, comm. port, and
N2 address (if N2 Bus).
4. Select OK.
6. Review controller information.
7. Exit Commissioning.
8. If adjustments were made, save
changes to controller and to file.
9. Unplug MM-CVT101-1 or AS-CBLPRO-2..
PROFLO40
